Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan

Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan
Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan
Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan

Large Image :  Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV，ISO
Model Number: Ruly0053
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan

Description
Application: Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop Usage: Steel Structure Workshop, Metal Warehouse, Factory Buildings, Garment Factory, Clothes Plant
Type: Steel Structure Workshop Working Scope: Design,Fabrication, Installation
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Glass Wool
Highlight:

prefab steel buildings

,

metal workshop building

Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop
Product Specifications
Application Truss Roof Steel Structure Buildings / Ready Made Structural Steel Workshop
Usage Steel Structure Workshop, Metal Warehouse, Factory Buildings, Garment Factory, Clothes Plant
Type Steel Structure Workshop
Working scope Design, Fabrication, Installation
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Glass wool
Product Overview

Truss Roof Steel Structure Buildings are ideal for automobile spare parts storage and similar industrial applications. The H steel truss beam roof design provides superior strength and efficiency compared to solid web steel beams, making it perfect for large-span buildings, exhibition halls, stadiums, and bridges.

The truss structure features concentrated tension and compression sections arranged at the upper and lower ends, maximizing bending strength while optimizing material usage.

Project Specifications
Name Prefabricated Steel Truss Roof Steel Workshop
Structure Type Portal frame, two ridges, two spans with office and storeroom building
Length 200m
Width 175m
Eave Height 15m
Roof Slope Flat
Gable Wall Column Spacing 7.5m
Roof 75 mm thick PU sandwich panel
Wall 75 mm thick PU sandwich panel
Door Sliding door
Window Ribbon Skylight
Height difference between indoor and outdoor 300mm
Technical Components
Main Steel Frame System
Main structure H section steel Q355, alkyd painting, two primary painting, two finish painting
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Ordinary bolt Galvanized bolt M20
Ordinary bolt Galvanized bolt M12
Brace nut Galvanized bolt M12
Bracing System
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Roof panel PU sandwich panel
Wall panel PU sandwich panel
Edge cover 0.5mm color plate, angle Alu
Fittings & accessories Nails, glue etc
Unpowered ventilator Diameter Φ600, stainless steel
Sky lighting band 1.2mm FRP, double layer
Sliding door sandwich panel door
Roof Drainage System
Gutter 0.5mm color steel plate
Rainspout pipes Φ110 PVC pipe
Production Process

Our steel structure production line ensures high-quality fabrication of truss roof beams:

Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan 0
Installation Options
  • Method 1: We provide detailed shop drawings prior to installation
  • Method 2: Comprehensive installation training at our factory, including assembly of sample structures when needed
Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan 1
Packaging & Transportation

All components including structure elements, panels, bolts, and accessories are securely packed in standard ocean transportation containers (40'HQ). Our skilled workers use cranes and forklifts to prevent damage during loading.

Truss Roof Steel Workshop with PU Sandwich Panels 50-Year Lifespan 2
Our Capabilities

We specialize in manufacturing both light and heavy steel structure buildings including:

  • Warehouses and workshops
  • Storage facilities and construction materials
  • High-rise steel office buildings
  • Factories and industrial plants
  • Exhibition halls and specialized steel structures
Request a Quote

Please provide the following information for an accurate quotation:

1. Location (where will be built?) _____country, area
2. Size: length*width*height _____mm*_____mm*_____mm
3. Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4. Snow load (max. snow height) _____kn/m2, _____mm
5. Anti-earthquake requirements _____level
6. Brickwall needed or not If yes, 1.2m high or 1.5m high
7. Thermal insulation requirements EPS, fiberglass wool, rockwool, or PU sandwich panels
8. Door quantity & size _____units, _____(width)mm*_____(height)mm
9. Window quantity & size _____units, _____(width)mm*_____(height)mm
10. Crane requirements If yes, _____units, max. lifting weight____tons; max. lifting height _____m
