Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel

Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel
Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel

Large Image :  Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0117
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month

Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel

Description
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting
Shot Blasting Level: Sa 2.5 Service Life: 50 Years
Wall And Roof: Sandwich Panel Type: Portal Frame Steel Workshop
Working Scope: Design,Fabrication, Installation Application: Logistics Warehouse, Workshop, Plant
Highlight:

prefab steel buildings

,

metal workshop building

Pre Engineered Steel Building Workshop Garage Portal Frame Sandwich Panel
Product Specifications
Attribute Value
Raw steel material Q235B, Q355B
Surface treatment Painting
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Sandwich panel
Type Portal frame steel workshop
Working scope Design, Fabrication, Installation
Application Logistics warehouse, workshop, plant
Product Overview

The Pre Engineered Steel Building Workshop Garage Portal Frame Sandwich Panel is designed for steel structure factories, warehouses, workshops, and office buildings. Suitable for both single-story large-span and multi-storey constructions, it offers superior space efficiency and structural strength.

Key Advantages
  • Provides large effective space with minimal structural footprint
  • Superior strength-to-weight ratio compared to concrete structures
  • Allows for 50% larger openings than concrete structures
  • Flexible design options for various industrial applications
  • Long service life of 50 years with proper maintenance
Technical Specifications
Item Details
Material Carbon structural steel (Q235B, Q345B or custom)
Production Lead Time Typically 45 days after down payment (varies by quantity)
Quality Certification Factory quality certificate, third-party available upon request
Dimensions H beam: 4000-15000mm length
Thickness Web plate: 6-32mm, Wing plate: 6-40mm
Height 200-1200mm
Color Options Customizable to customer requirements
Minimum Order Quantity 1000 m² (width × length × eave height)
Structural Components
  • Main Frame: H Steel beams and columns (Q235/Q345 steel), painted or galvanized
  • Secondary Frame: Galvanized C or Z purlins, steel bracing, tie bars, knee braces
  • Roof & Wall: PU sandwich panel, Rockwool sandwich panel, or corrugated steel sheet
  • Surface Treatment: Two layers of rust-proof paint or hot-dip galvanized
  • Accessories: Skylight belts, ventilators, down pipes, gutters, flashing, etc.
Our Services
  • Complete steel fabrication including painting and galvanizing
  • Design, fabrication, and installation of prefabricated steel structures
  • Custom fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel 0
Packing and Transportation

All structural components, panels, bolts, and accessories are packed securely for ocean transportation in 40'HQ containers. Our skilled workers handle loading with cranes and forklifts to prevent damage during transit.

Pre Engineered Steel Building Workshop Portal Frame Sandwich Panel 1
Request a Quote

To provide an accurate quote, we require the following information:

  • Project location (country and area)
  • Building dimensions (length × width × height)
  • Environmental loads (wind speed, snow height)
  • Earthquake resistance requirements
  • Insulation and wall specifications
  • Door and window requirements
  • Crane specifications if needed
