Prefab Steel Structure Warehouse with Light Steel Frame

Prefab Steel Structure Warehouse with Light Steel Frame
Prefab Steel Structure Warehouse with Light Steel Frame
Prefab Steel Structure Warehouse with Light Steel Frame Prefab Steel Structure Warehouse with Light Steel Frame Prefab Steel Structure Warehouse with Light Steel Frame Prefab Steel Structure Warehouse with Light Steel Frame Prefab Steel Structure Warehouse with Light Steel Frame Prefab Steel Structure Warehouse with Light Steel Frame Prefab Steel Structure Warehouse with Light Steel Frame

Large Image :  Prefab Steel Structure Warehouse with Light Steel Frame

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0122
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Warehouse with Light Steel Frame

Description
Features: Steel Structure Warehouse Application: Prefab Structure Steel Buildings, Light Steel Frame Structure
Type: Portal Frame Structure Working Scope: Design,Fabrication, Installation
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting
Service Life: 50 Years Wall And Roof: Glass Wool
Highlight:

steel structure building

,

metal storage buildings

Prefab Structure Steel Buildings Material Warehouse Light Steel Frame Structure
Product Specifications
Attribute Value
Application Prefab Structure Steel Buildings, Light Steel Frame Structure
Features Steel Structure Warehouse
Type Portal Frame Structure
Working scope Design, Fabrication, Installation
Raw steel material Q235B, Q355B
Surface treatment Painting
Service life 50 Years
Wall and Roof Glass wool
Project Overview

Our prefabricated steel structure buildings are designed for warehouse and workshop applications. The structural system consists of:

  • Transverse structural system: Trusses (roof trusses, beams, and columns) that withstand roof loads, wind, earthquakes, and crane operations
  • Longitudinal structural system: Columns, inter-column supports, and wall beams forming a rigid space skeleton
Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Roof Components Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Sky light: 6mm thick PVC
Wall Components Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Accessories Glass cement, self-tapping screws, ventilation ball, doors & windows
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Prefab Steel Structure Warehouse with Light Steel Frame 0
Quality Control Standards
  • 100% dimensional tolerance testing (<1mm)
  • 20% ultrasonic testing of welding lines (full penetration, no faults)
  • 20% magnetic powder testing (smooth, defect-free surfaces)
  • Third-party inspection assistance available
Prefab Steel Structure Warehouse with Light Steel Frame 1
Quotation Requirements

Please provide the following information for an accurate quote:

Item Details Required
1 Location (country, area where building will be constructed)
2 Building dimensions (length × width × height in mm)
3 Maximum wind load (kn/m², km/h, or m/s)
4 Maximum snow load (kn/m² or mm)
5 Earthquake resistance level required
6 Brick wall requirements (height if needed)
7 Thermal insulation specifications (material preference if needed)
8 Door quantity and dimensions (width × height in mm)
9 Window quantity and dimensions (width × height in mm)
10 Crane specifications (quantity, max lifting weight in tons, max height in meters if needed)
