SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse

SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse
SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse

Large Image :  SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0241
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Packaging Details: As request
Delivery Time: 15 ~ 20 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 Square Meter Per Month

SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse

Description
Features: Galvanized Metal Buildings Application: Light Steel Structure Warehouse
Type: Steel Structure Warehouse Working Scope: Design,Fabrication, Installation
Raw Steel Material: Q235B, Q355B, ASTM A36 Service Life: 50 Years
Wall And Roof: Steel Cladding Sheet Surface Treatment: Painting
High Light:

Hot dip Prefabricated Steel Warehouse

,

Stable Prefabricated Steel Warehouse

,

SGS Industrial Steel Frame Buildings

Environmentally Friendly And Stable Prefabricated Steel Warehouse

Construction Design Prefabricated Steel Structure Warehouse With Low Cost



Steel structure warehouse is a new type of building structure system, which is formed by the main steel framework linking up H section, Z section and U section steel components, roof and walls using a variety of sandwich panels or corrugated steel color sheet and other components such as windows and doors. It can be single span, multiple spans, and multiple stories with different using purpose. Steel structure warehouse is widely used for storage, logistic center, distribution center, etc… As a new type of steel building system, steel structure warehouse has the following advantages:



1. Environmental friendly and energy conversing;
2. Fast construction and easy erection;
3. Wide span can be 60m without middle columns;
4. Long life span up to 50 years;
5. Stable and earth quake proof up to 9 points.



SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse 0

SPECIFICATION OF STEEL STRUCTURE MATERIAL:



Item name Specification Material Parameter Technical Treatment
Column H shape,Box,steel pipe,Hot rolled sheet Q235B,Q345B Paint or Hot dip galvanized
Beam H shape,steel Truss,Hot rolled sheet Q235B,Q345B Paint or Hot dip galvanized
Bracing Steel rod,Steel pipe,Angle steel Q235B,Q345B
Purling C or Z shape, purling Thickness:1.8mm~3.0mm Q235B,Q346B Hot dip galvanized
Wall and roof panel EPS,Rock wool,Pu,Glass wool Sandwich panel or Single sheet. Steel T=0.426~0.8mm,insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet,T=1.0~1.5mm Paint or Hot dip galvanized
Window alloy-Glass,Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion:2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel,stainless steel,PC Paint or Hot dip galvanized,304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized,304
Downpipe PVC pipe,Color steel pipe T=0.5mm Φ110,160,200 Paint
Bolt Ordinary, high strength 10.9S,4.8s Hot dip galvanized
Anchor bolt Steel rod M24,M27 M30 Q235B



OUR STEEL STRUCTURE FACTORY:



The floor space of our steel structure fabrication factory is 35,000㎡, and the workshop area is 20000㎡. We own three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various types of profiling steel sheet machines with advanced equipment such as plasma cutting machine.



SGS Hot Dip Galvanized Stable Prefabricated Steel Warehouse 1





Sinoacme steel structure production procedure:



Design: The design will be made with full design parameters provided by clients;
Material: Raw material will be prepared according to the material list provided by engineers;
Cutting: Steel plate will be cut according to the detailed drawing provided by engineers;
Assembling: Apply spot welding to assemble two pieces flange plate and one web plate together;
Auto welding: Arc-submerging machine will be applied to make full welding for steel components;
Straightening: To make the deformation of flange and web plate to flat;
Manual welding: Welding the connection plate and purlin plate to the main steel components;
Shot blasting: To get rid of rust on the surface of steel components;
Painting: Antiseptic treatment;
Delivery: Packing, loading and deliver to construction site;
Erection: Erect according to the erection drawing provided by engineers;
Finishing: Whole project completed.



OUR SERVICE:



OEM&ODM Service, We can quote according to your drawings
Pre-Sales Service 1.Consultant service (Answering client's questions)
2.Primary design plan(Free)
3.Assisting client to choose suitable construction plan
4.Price calculation
5.Business&technology discussion
Sale Service 1.Submission of support reaction data for foundation
2.Submission of construction drawing
3.Providing requirements for embedding
4Construction Manual
5.Fabrication & Packing
6.Statistical table of material
7.Delivery on time
8.Other requirements by Clients
After-Sale Service 1.Service of installation Supervision
2.Instruction for using after installation completed
