Prefabricated Steel Structure Warehouse with 50-Year Lifespan

Prefabricated Steel Structure Warehouse with 50-Year Lifespan
Prefabricated Steel Structure Warehouse with 50-Year Lifespan
Prefabricated Steel Structure Warehouse with 50-Year Lifespan Prefabricated Steel Structure Warehouse with 50-Year Lifespan Prefabricated Steel Structure Warehouse with 50-Year Lifespan Prefabricated Steel Structure Warehouse with 50-Year Lifespan Prefabricated Steel Structure Warehouse with 50-Year Lifespan Prefabricated Steel Structure Warehouse with 50-Year Lifespan Prefabricated Steel Structure Warehouse with 50-Year Lifespan

Large Image :  Prefabricated Steel Structure Warehouse with 50-Year Lifespan

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0391
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Packaging Details: As request
Delivery Time: 15 ~ 20 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Structure Warehouse with 50-Year Lifespan

Description
Features: Prefabricated Steel Structure Building Application: Steel Structure Logistics Park
Type: Steel Structure Warehouse Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Steel Cladding Sheet
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

Prefabricated Steel Structure Logistics Park

,

Hot Dip Galvanized Steel Structure Warehouse

,

BV H Shaped Steel Structure Warehouse

Prefabricated Steel Structure Warehouse Logistics Park Hot Dip Galvanized
Product Attributes
Attribute Value
Application Steel Structure Logistics Park
Features Prefabricated Steel Structure Building
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Steel cladding sheet
Surface treatment Painting
Working scope Design, Fabrication, Installation
Product Description

This prefabricated steel structure warehouse is designed for logistics parks and industrial applications, featuring hot-dip galvanized components for enhanced durability.

Key Features
  • Three-span design with 5T overhead cranes in each span
  • Main steel frame constructed with welded H-shaped steel beams & columns
  • Roof and wall panels made of rock wool sandwich panels
  • Versatile applications including warehouses, factories, workshops, and more
  • Engineered portal frame structure system
Prefabricated Steel Structure Warehouse with 50-Year Lifespan 0
Material Specifications
Item name Specification Material Parameter Technical Treatment
Column H shape, Box, steel pipe, Hot rolled sheet Q235B, Q345B Paint or Hot dip galvanized
Beam H shape, steel Truss, Hot rolled sheet Q235B, Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B, Q345B
Purling C or Z shape, purling Thickness:1.8mm~3.0mm Q235B, Q346B Hot dip galvanized
Wall and roof panel EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Prefabricated Steel Structure Warehouse with 50-Year Lifespan 1
Quality Control
  • Raw material thickness tolerance <0.25mm
  • 100% dimension testing with tolerance <1mm
  • 20% sample welding line ultrasonic testing
  • Shot blasting grade Sa. 2.5 with roughness >75um
  • Paint primer application within 5 hours after shot blasting
  • Dry Film Thickness (DFT) >75UM
Prefabricated Steel Structure Warehouse with 50-Year Lifespan 2
Packing & Loading

All structural components, panels, bolts and accessories are packed for ocean transportation in 40'HQ containers. Loading is performed by skilled workers using cranes and forklifts to prevent damage.

Prefabricated Steel Structure Warehouse with 50-Year Lifespan 3
