Product Description
Steel structure plant features:
1. steel structure building light weight, high strength, large span.
2. steel structure construction period is short, reduce the investment cost accordingly.
3. steel structure building fire resistance is poor, corrosion resistance, low temperature areas should not use steel structure.
4. steel structure building is easy to move, recycling pollution-free.
Material list
| Steel Frame |
H section steel |
Q235steel plate thickness: 8-30mm |
| Welding |
Automatic submerged arc welding |
| Rust removal |
Sand blasting |
| Surface finish |
Alkyd paint or galvanized |
| Intensive bolt |
M20,Grade 10.9 |
| Supporting System |
Angle brace |
L50x4,Steel Q235, processed and painted |
| Horizontal brace |
Φ20, Steel Q235, processed and painted |
| Column brance |
Φ20, Steel Q235, processed and painted |
| Tie rod |
Φ89*3, Steel Q235, processed and painted |
| Ordinary bolt |
M12 Galvanized bolt |
| Roof |
Purlin |
C160*60*2.5,Steel Q235, galvanized and painted |
| Roof panel |
Sandwich panel or corrugated steel sheet |
| Sky light |
6mm thick PVC |
| Accessories |
Glass cement, self-tapping screws, etc. |
| Edge cover |
0.4mm steel sheet profile trimming |
| Gutter |
0.4mm thick sheet steel profile or galvanized sheet |
| Down pie |
Φ110PVC |
| Walls |
Purlin |
C160*60*2.5,Steel Q235, painted |
| Wall |
Sandwich panel or corrugated steel plate |
| Accessories |
Glass cement, self-tapping screws, etc. |
| Edge cover |
0.4mm steel sheet profile trimming |
| Ventilation |
Ventilation ball |
| Doors & windows |
Rolling door/sliding door PVC/alu/steel/window |
Our Company
· Professional engineers team,designed and quoted quickly.
· Our steel structures are sold to more than 30 countries and regions.
· 30,000 square meters of self-owned factory.
· The annual output exceeds 18000 tons of steel structures.
· Number of active employees exceeds 100.
Our Certificates
Hot Projects
Production Process
Design Service
Our design team can deepen or design the fabrication drawing or shop drawing based on your architectural drawing and construction drawing.
Packing & Transport
Firstly, the steel components are fixed on the pallet with steel ropes; secondly, the pallet is lifted by the gantry crane, and at the same time pushed into the container by the forklift truck; lastly, the steel ropes are used to fix the pallet and the steel components again to prevent them from falling off.
FAQ
Q: You are manufacture factory or trading company?
A: We are manufacture factory. And you are welcomed to visit us at any time. The quality control flow and sales team will show you our professionalism. Also you will can get best and most competitive price after visiting us.
Q: Is your price competitive compared with other companies?
A: Our business objectives are to give the best price with same quality and best quality with the same price. We will do everything we can to reduce your cost and guarantee you get the best product that you paid for.
Q: Can you send engineers or whole team to install my project?
A: We will give detailed installation drawings for free. We can send engineers as installation director or a team upon request.
Q: Do you accept container loading inspection?
A: You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
Q: Do you offer designing service for us?
A: Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial building like office mansion, super marker, auto dealer shop, shipping mall, 5 star hotel.
Q: What is the delivery time?
A: Delivery time depends on order quantities. In general the delivery time to nearest seaport in China will be 40 days after receiving deposit.
Q: How can you get a quotation for your projects?
A: You can contact us by email, phone, WhatsApp,Viber and so on 24*7 and you will get reply within 8 hours.
