Product Details:
|
| Features: | Prefab Steel Structure, Large Span, Multi-Floor | Raw Steel Material: | Q235B, Q355B, ASTM A36 |
|---|---|---|---|
| Surface Treatment: | Painting , Hot-DIP Galvanized | Service Life: | 50 Years |
| Wall And Roof: | Steel Cladding Sheet,Sandwich Panel | Columns & Beams: | H-Section Steel |
| Shot Blasting Level: | SA 2.5 | Certification: | CE, AISC, SGS, BV, ISO, GB |
| Drawing: | CAD, TEKLA, 3D Model, PKPM, BIM | Production Capacity: | 1500ton/month |
| Connection Form: | Bolt Connection | Parapet Wall: | As Requested |
| Roof Type: | Single,Multi Roof | Color: | Customized |
| Design Load: | Wind,Snow,Earthquake | ||
| Highlight: | steel warehouse fast installation,high wind resistance steel warehouse,steel structure warehouse durable |
||
| Component | Specification |
|---|---|
| Main Steel Frame (Column) | Q235, Q355 Welded H Section Steel |
| Main Steel Frame (Beam) | Q235, Q355 Welded H Section Steel |
| Purlin | Q235 C and Z purlin |
| Knee bracing | Q235 Angle Steel |
| Tie Bar | Q235 Circular Steel Pipe |
| Bracing | Q235 Round Bar |
| Column and Horizontal Bracing | Q235 Angle Steel, Round Bar or Steel Pipe |
| Roof Panel | EPS Sandwich Panel / Fiber Glass Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
| Window | Aluminium Alloy Window / PVC Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
| Downspout | PVC |
| Structure Usage | Up to 50 years |
| Finishing Options | Vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) or galvanized. |
Service Advantages
