Prefab Steel Structure Building for Automobile 4S Store CE Certified

Large Image : Prefab Steel Structure Building for Automobile 4S Store CE Certified

Product Details:

Place of Origin:	Qingdao,China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RULYC012

Payment & Shipping Terms:

Minimum Order Quantity:	200 square meters
Price:	USD19-USD39 Per Square Meter
Packaging Details:	40HQ/Open top container
Delivery Time:	20 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	20,000 square meters or 1,500 tons per month

Contact Now

Prefab Steel Structure Building for Automobile 4S Store CE Certified

Description

Features:	Prefab Steel Structure, Large Span, Multi-Floor	Raw Steel Material:	Q235B, Q355B, ASTM A36
Application:	Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part	Surface Treatment:	Painting Or Hot-DIP Galvanized
Service Life:	50 Years	Wall And Roof:	Steel Cladding Sheet,Sandwich Panel
Columns & Beams:	H-Section Steel	Shot Blasting Level:	SA 2.5
Certification:	CE, AISC, SGS, BV, ISO, GB	Installation:	Engineer Guidance On Site
Drawing:	CAD, TEKLA, 3D Model, PKPM, BIM	HS Code:	9406900090
Transport Package:	Standard Export Package Or Customer′s Requirement	Production Capacity:	30000ton/Year
Connection Form:	Bolt Connection
Highlight:	Prefabricated Portal Steel Structure Building , Portal Steel Structure Building , Modern Steel Structure Building

Prefabricated Portal Steel Structure Building for Automobile 4S Stores

This modern steel structure provides an efficient, durable solution for vehicle dealerships, combining strength with aesthetic appeal through prefabricated construction.

Key Specifications

Attribute	Value
Raw Steel Material	Q235B, Q355B, ASTM A36
Application	Steel Workshop, Structural Roofing, Frame Components
Surface Treatment	Painting or Hot-DIP Galvanized
Service Life	50 Years
Certification	CE, AISC, SGS, BV, ISO, GB

Structural Components

Main Steel Frame: H section steel Q355 with alkyd painting (2 primer + 2 finish coats)

Roof/Wall Purlin: XZ160*60*20*2.5 galvanized

Bolting System: Grade 10.9 intensive bolts, M20/M24 anchor bolts, galvanized M12/M20 standard bolts

Bracing System

Component	Specification
Cross Brace	Φ20 round steel bar Q235, painted
Angle Brace	L50*5 angle steel Q235, painted
Column Bracing	Φ25 round steel bar Q235, painted

Wall & Roof System

Corrugated steel plates or insulated sandwich panels (EPS/fiber glass/rock wool/PU)
1.2mm FRP skylight bands (double layer)
Φ600 stainless steel ventilators
Complete drainage system with color steel gutters and PVC pipes

Manufacturing Capabilities

Qingdao Ruly Steel Engineering Co., Ltd specializes in steel structure design, fabrication and construction with 35,000m² facility and 3,000 ton/month production capacity.

Quality Assurance

AWS D1.1, CE (EN 1090-1), ISO certifications
Dedicated QC team for material and production inspection
SGS and BV certified manufacturing processes

Packaging & Shipping

All components are packed for ocean transport in 40'HQ containers using protective materials and proper loading equipment to prevent damage.

Request a Quote

Provide these details for an accurate quotation:

Information Needed	Details Required
Location	Country and construction area
Structural Requirements	Dimensions, wind/snow loads, seismic rating
Material Specifications	Insulation type, wall/roof panel preferences
Special Features	Door/window quantities, crane requirements
