Double Storey Prefabricated Steel Warehouse with H-Section Beams

Double Storey Prefabricated Steel Warehouse with H-Section Beams
Double Storey Prefabricated Steel Warehouse with H-Section Beams Double Storey Prefabricated Steel Warehouse with H-Section Beams Double Storey Prefabricated Steel Warehouse with H-Section Beams Double Storey Prefabricated Steel Warehouse with H-Section Beams Double Storey Prefabricated Steel Warehouse with H-Section Beams Double Storey Prefabricated Steel Warehouse with H-Section Beams Double Storey Prefabricated Steel Warehouse with H-Section Beams

Large Image :  Double Storey Prefabricated Steel Warehouse with H-Section Beams

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0386
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: Steel frame pallets and loaded into 40’HQ Electronic Tube & Transistor
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month

Double Storey Prefabricated Steel Warehouse with H-Section Beams

Description
Features: Double Storey Steel Structure Warehouse Application: Prefabricated Steel Buildings
Type: Prefabricated Steel Buildings Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Glass Wool Sandwich Panel
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Columns & Beams: H-section Steel Standard: AISC, ASTM, BS, DIN, GB, JIS
Highlight:

Double Storey Q235B Steel Structure Warehouse

,

Painting Prefab Steel Structure Warehouse

,

Prefabricated Welded H Section Steel Buildings

Double Storey Steel Structure Warehouse Prefabricated
Product Specifications
Attribute Value
Application Prefabricated Steel Buildings
Features Double Storey Steel Structure Warehouse
Type Prefabricated Steel Buildings
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Glass wool sandwich panel
Surface treatment Painting
Working scope Design, Fabrication, Installation
Columns & Beams H-section steel
Standard AISC, ASTM, BS, DIN, GB, JIS
Product Description

Prefabricated Steel Structure Building/Double Storey Steel Structure Warehouse designed for production and storage of handmade products. Our steel structure buildings consist of steel columns, beams, purlins and other components that form a durable, lightweight load-bearing structure. This cost-efficient building solution offers excellent long-term value.

Steel Structure Material Specifications
Items Specification
Main Steel Frame - Column Q235, Q345 Welded H Section Steel
Main Steel Frame - Beam Q235, Q345 Welded H Section Steel
Secondary Frame - Purlin Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system - Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Maintenance system - Wall Panel Sandwich Panel / Corrugated Steel Sheet
Accessories - Window Aluminium Alloy Window / PVC Window / Sandwich Panel Window
Accessories - Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Live load on Roof 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
Temperature Suitable temperature: -50°C~+50°C
Certification CE, SGS, ISO9001:2008, ISO14001:2004
Finishing Options Vast array of colors and textures available
Paint Options Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized
Our Steel Structure Fabrication Factory

Our 35,000㎡ fabrication facility includes 20,000㎡ of workshop space equipped with three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines, and advanced profiling steel sheet machines including plasma cutting equipment.

Double Storey Prefabricated Steel Warehouse with H-Section Beams 0
Installation Process

We provide detailed construction drawings prior to installation and can dispatch engineers to guide on-site installation or complete the installation with our professional construction team.

Double Storey Prefabricated Steel Warehouse with H-Section Beams 1
Packing and Transportation

All structural components, panels, bolts and accessories are securely packed for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to carefully load goods at our factory to prevent damage during transit.

Double Storey Prefabricated Steel Warehouse with H-Section Beams 2
Our Competitive Advantages
1 Professional design team
We create custom drawings based on your requirements or calculate steel quantities from your existing plans.
2 Skilled fabrication team and advanced equipment
We develop independent production schedules for each project and provide comprehensive worker training before fabrication begins.
3 One-stop service
We offer complete project solutions tailored to your specifications, drawing on our extensive experience with customized steel structures.
4 Professional QC team
Our quality control team ensures all products and services meet your exact requirements.
5 After sales service
We provide ongoing support for maintenance of insulation and steel components throughout the building's lifespan.
