Q235B Q355B Prefabricated Steel Structure Warehouse Building

Q235B Q355B Prefabricated Steel Structure Warehouse Building
Q235B Q355B Prefabricated Steel Structure Warehouse Building
Q235B Q355B Prefabricated Steel Structure Warehouse Building Q235B Q355B Prefabricated Steel Structure Warehouse Building Q235B Q355B Prefabricated Steel Structure Warehouse Building Q235B Q355B Prefabricated Steel Structure Warehouse Building Q235B Q355B Prefabricated Steel Structure Warehouse Building Q235B Q355B Prefabricated Steel Structure Warehouse Building Q235B Q355B Prefabricated Steel Structure Warehouse Building

Large Image :  Q235B Q355B Prefabricated Steel Structure Warehouse Building

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV
Model Number: Ruly0353
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Q235B Q355B Prefabricated Steel Structure Warehouse Building

Description
Application: Prefabricated Steel Structure Building Type: Steel Structure Warehouse
Working Scope: Design,Fabrication, Installation Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Or Hot-dip Galvanize Shot Blasting Level: Sa 2.5
Service Life: 50 Years Wall And Roof: Glass Wool
Highlight:

Q355B Steel Construction Warehouse

,

Q235B Prefabricated Metal Warehouse

,

Hot Dip Galvanized Structural Steel Warehouse

Q235B Q355B Prefabricated Steel Structure Building Hardware Warehouse
Product Specifications
Attribute Value
Application Prefabricated Steel Structure Building
Type Steel Structure Warehouse
Working scope Design, Fabrication, Installation
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Glass wool
Product Overview

Our prefabricated steel structure building hardware warehouse features modern structural design enabled by computer-aided analysis software, allowing for rapid design cycles and easy modifications. The prefabricated nature enables efficient factory production combined with on-site assembly, significantly reducing construction timelines while maintaining high precision.

Structural Components and Technical Parameters
Main Steel Frame System
  • Main structure: H section steel Q355 with alkyd painting (two primary coats, two finish coats)
  • Roof purlin: XZ160*60*20*2.5, galvanized
  • Wall purlin: XZ160*60*20*2.5, galvanized
  • Intensive bolt: Grade 10.9
  • Turn buckle bolt: M20+2, steel Q235
  • Anchor bolt: M24, steel Q235
  • Various galvanized bolts (M20, M12)
Bracing System
  • Cross brace: Φ20 round steel bar Q235, painted
  • Angle brace: L50*5 angle steel Q235, painted
  • Column bracing: Φ25 round steel bar Q235, painted
  • Tie bar: Φ127*3 steel pipe Q235, painted
  • Batter brace: Φ32*2.5, Φ12 round steel bar Q235, painted
Wall & Roof System
  • Roof panel: Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
  • Wall panel: Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
  • Edge cover: 0.5mm color plate, angle Alu.
  • Unpowered ventilator: Diameter Φ600, stainless steel
  • Sky lighting band: 1.2mm FRP, double layer
  • Sliding door: sandwich panel door
Q235B Q355B Prefabricated Steel Structure Warehouse Building 0
Our Manufacturing Facility
Q235B Q355B Prefabricated Steel Structure Warehouse Building 1
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Complete design, fabrication and installation services
  • Shop drawing development based on architectural plans
  • Engineering consulting services
Q235B Q355B Prefabricated Steel Structure Warehouse Building 2
Packaging & Shipping

All components including structure elements, panels, bolts and accessories are packed securely for ocean transportation in 40'HQ containers. Our skilled workers handle loading using cranes and forklifts to prevent damage.

Q235B Q355B Prefabricated Steel Structure Warehouse Building 3
Why Choose Our Steel Structures
  • Professional design team for customized solutions
  • Skilled fabrication with advanced equipment
  • Complete project management for each installation
  • Strict quality control processes
  • Comprehensive after-sales support
Quotation Information Required
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake requirements _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation requirements EPS, fiberglass wool, rockwool, PU sandwich panels or metal sheets
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane requirements If yes, _____units, max. lifting weight____tons; max. lifting height _____m
