Prefabricated Steel Structure Warehouse for Logistics Parks

Prefabricated Steel Structure Warehouse for Logistics Parks
Prefabricated Steel Structure Warehouse for Logistics Parks
Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks

Large Image :  Prefabricated Steel Structure Warehouse for Logistics Parks

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV，ISO
Model Number: Ruly0343
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Structure Warehouse for Logistics Parks

Description
Application: Steel Structure Logistics Park Type: Steel Structure Warehouse
Surface Treatment: Painting Or Hot-dip Galvanize Shot Blasting Level: Sa 2.5
Service Life: 50 Years Wall And Roof: Glass Wool
Working Scope: Design,Fabrication, Installation
Highlight:

Steel Structure Logistics Park

,

Steel Structure Logistics Warehouse

,

Logistics Park Steel Structure Building

Steel Structure Logistics Park Warehouse
Prefabricated steel structure building designed for logistics parks, offering fast construction, automation compatibility, and energy efficiency.
Product Specifications
Attribute Value
Application Steel Structure Logistics Park
Type Steel Structure Warehouse
Surface treatment Painting or Hot-dip Galvanize
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Glass wool
Working scope Design, Fabrication, Installation
Project Details
Feature Specification
Structure Type Portal frame, single ridge, single span
Dimensions 60m (L) × 30m (W) × 9m (H)
Roof Slope Flat
Gable Wall Column Spacing 7.5m
Roof Material 0.5mm steel cladding sheet
Wall Material 0.5mm steel cladding sheet
Door Type Sliding door
Window Type Ribbon Skylight
Structural Components
Main Steel Frame System: H section steel Q355 with alkyd painting, galvanized roof and wall purlins (XZ160*60*20*2.5), grade 10.9 intensive bolts.
Bracing System: Cross brace (Φ20 round steel bar), angle brace (L50*5 angle steel), column bracing (Φ25 round steel bar), all Q235 with alkyd painting.
Wall & Roof System: 0.5mm steel cladding sheets, stainless steel unpowered ventilator (Φ600), 1.2mm FRP skylight, sandwich panel sliding doors.
Production Capabilities
Our 35,000㎡ fabrication facility includes three H steel production lines, BOX production lines, C/Z purlin lines, and advanced profiling equipment.
Prefabricated Steel Structure Warehouse for Logistics Parks 0
Service Scope
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated buildings
  • Shop drawing development from architectural plans
  • Engineering consulting services
Prefabricated Steel Structure Warehouse for Logistics Parks 1
Packaging & Shipping
All components are packed for ocean transportation in 40'HQ containers, loaded by skilled workers using cranes and forklifts to prevent damage.
Prefabricated Steel Structure Warehouse for Logistics Parks 2
Quotation Requirements
Item Information Required
1 Location (country, area)
2 Size (L×W×H in mm)
3 Wind load (max. wind speed)
4 Snow load (max. snow height)
5 Earthquake resistance level
6 Brickwall requirements (height if needed)
7 Thermal insulation specifications
8 Door quantity & dimensions
9 Window quantity & dimensions
10 Crane specifications (if needed)
