Prefabricated Steel Structure Warehouse for Logistics Parks

Prefabricated Steel Structure Warehouse for Logistics Parks
Prefabricated Steel Structure Warehouse for Logistics Parks
Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks Prefabricated Steel Structure Warehouse for Logistics Parks

Large Image :  Prefabricated Steel Structure Warehouse for Logistics Parks

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0341
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: Steel frame pallets and loaded into 40’HQ
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Structure Warehouse for Logistics Parks

Description
Application: Prefabricated Steel Structure Logistics Park Type: Steel Structure Warehouse
Raw Steel Material: Q235B, Q355B, ASTM A36 Service Life: 50 Years
Wall And Roof: Rock Wool Surface Treatment: Painting
Working Scope: Design,Fabrication, Installation Columns & Beams: H-section Steel
Standard: AISC, ASTM, BS, DIN, GB, JIS
Highlight:

Steel Structure Logistics Park

,

Prefabricated Steel Logistics Park

,

Logistics Park Steel Structure Building

Prefabricated Steel Structure Logistics Park Steel Structure Building
Product Specifications
Attribute Value
Application Prefabricated Steel Structure Logistics Park
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Rock wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Columns & Beams H-section steel
Standard AISC, ASTM, BS, DIN, GB, JIS
Product Description
With the rapid development of the logistics industry, steel structure warehouses have evolved to meet modern demands. Our prefabricated steel structures offer superior solutions compared to traditional warehouses, featuring advanced automation and efficient space utilization.
Steel structure logistics warehouses represent the cutting edge of storage technology, combining:
  • Steel structure shelving systems
  • Automated stackers and working platforms
  • Computer-controlled access and operation systems
  • Barcode management technology
Material Specifications
Component Specification
Main Steel Frame (Column) Q235, Q345 Welded H Section Steel
Main Steel Frame (Beam) Q235, Q345 Welded H Section Steel
Secondary Frame (Purlin) Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance System Specifications
Component Options
Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Window Aluminium Alloy Window / PVC Window / Sandwich Panel Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Performance Specifications
Live load on Roof 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
Temperature Range -50°C to +50°C
Certifications & Finishing
Certifications: CE, SGS, ISO9001:2008, ISO14001:2004
Finishing Options: Wide selection of colors and textures available
Paint Options: Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) or Galvanized
Prefabricated Steel Structure Warehouse for Logistics Parks 0
Our Manufacturing Facility
Our steel structure fabrication factory spans 35,000㎡ with 20,000㎡ of workshop space. We operate multiple production lines including:
  • Light/heavy H steel production lines
  • BOX production lines
  • C/Z purlin production lines
  • Advanced profiling steel sheet machines
  • Plasma cutting equipment
Prefabricated Steel Structure Warehouse for Logistics Parks 1
Installation Process
We provide detailed construction drawings prior to installation for each project. Our services include:
  • On-site engineering guidance
  • Complete installation by our professional construction team
Prefabricated Steel Structure Warehouse for Logistics Parks 2
