Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Prefab Steel Warehouse Structure Q235B Q355B ASTM A36
Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Large Image :  Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0315
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Packaging Details: As request
Delivery Time: 15 ~ 20 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Warehouse Structure Q235B Q355B ASTM A36

Description
Application: Prefab Steel Structure Warehouse Type: Steel Structure Warehouse
Raw Steel Material: Q235B, Q355B, ASTM A36 Working Scope: Design,Fabrication, Installation
Wall And Roof: Steel Cladding Sheet Service Life: 50 Years
Surface Treatment: Painting Standard: AISC, ASTM, BS, DIN, GB, JIS
Highlight:

Fabrication Prefab Steel Warehouse

,

QB355 Prefab Steel Warehouse

,

QB355 Construction Steel Structure

Fabrication Prefab Steel Warehouse With QB355 Construction Steel Structure
Product Attributes
Attribute Value
Application Prefab Steel Structure Warehouse
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Working scope Design, Fabrication, Installation
Wall and Roof Steel cladding sheet
Service life 50 Years
Surface treatment Painting
Standard AISC, ASTM, BS, DIN, GB, JIS
Product Description
Steel structure components are mainly composed of steel beams, steel columns, steel trusses and other components made of section steel and steel plates. These components are typically connected by welding seams, bolts or rivets to create factory buildings, warehouses, office buildings, and residences.
The steel structure building system offers significant advantages including light deadweight, factory production, fast installation, short construction period, excellent seismic performance, faster investment recovery, and minimal environmental pollution. Compared to reinforced concrete structures, steel structures excel in "high, big, light" applications and are widely used in construction projects globally.
Component Materials
Steel Frame H section steel | Q235/Q345 steel plate thickness: 8-30mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Horizontal brace: Φ20, Steel Q235, processed and painted
Column brace: Φ20, Steel Q235, processed and painted
Tie rod: Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Sky light: 6mm thick PVC
Accessories: Glass cement, self-tapping screws, etc.
Edge cover: 0.4mm steel sheet profile trimming
Gutter: 0.4mm thick sheet steel profile or galvanized sheet
Down pie: Φ110PVC
Walls Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Accessories: Glass cement, self-tapping screws, etc.
Edge cover: 0.4mm steel sheet profile trimming
Ventilation: Ventilation ball
Doors & windows: Rolling door/sliding door PVC/alu/steel/window
Product Testing
Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 0 Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 1
Main Characteristics of Steel Structure
  • Super Aseismatic: Cold formed steel members provide aseismatic grade up to 8
  • Wind Resistance: High strength structure can resist winds up to 50m/s
  • Durable: Painted or galvanized steel offers 50-70 year lifespan
  • Heat Insulation: Sandwich panels prevent "cold bridge" effect
  • Environment Protection: Minimal construction waste with 100% recyclable materials
  • Easy and Fast Build: 300m² structure can be completed in 30 days by 5 workers
Drawings & Quotation
Customized designs are available. Our design team can create solutions based on your specific project requirements. For accurate quotations and drawings, please provide your project details.
Packing
Prefab Steel Warehouse Structure Q235B Q355B ASTM A36 2

Tag:

steel structure building,

metal storage buildings,

metal warehouse construction
