Prefab Steel Structure Warehouse Building with Sandwich Panels

Prefab Steel Structure Warehouse Building with Sandwich Panels
Prefab Steel Structure Warehouse Building with Sandwich Panels
Prefab Steel Structure Warehouse Building with Sandwich Panels Prefab Steel Structure Warehouse Building with Sandwich Panels Prefab Steel Structure Warehouse Building with Sandwich Panels Prefab Steel Structure Warehouse Building with Sandwich Panels Prefab Steel Structure Warehouse Building with Sandwich Panels Prefab Steel Structure Warehouse Building with Sandwich Panels Prefab Steel Structure Warehouse Building with Sandwich Panels

Large Image :  Prefab Steel Structure Warehouse Building with Sandwich Panels

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0292
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Warehouse Building with Sandwich Panels

Description
Features: Steel Structure Warehouse Application: Steel Structure Factory Warehouse Building Prefab Structural Steel Frame Buildings
Type: Prefab Steel Buildings Wall And Roof: Glass Wool Sandwich Panel
Raw Steel Material: Q235B, Q355B, ASTM A36 Surface Treatment: Painting
Working Scope: Design,Fabrication, Installation Service Life: 50 Years
Highlight:

Prefab Steel Structure Factory Warehouse

,

Structural Steel Structure Factory Warehouse

,

Prefab Structural Steel Frame Buildings

Prefab Steel Structure Factory Warehouse Building Structural Steel Frame Buildings
Product Specifications
Attribute Value
Application Steel Structure Factory Warehouse Building Prefab Structural Steel Frame Buildings
Features Steel Structure Warehouse
Type Prefab Steel Buildings
Wall and Roof Glass wool sandwich panel
Raw steel material Q235B, Q355B, ASTM A36
Surface treatment Painting
Working scope Design, Fabrication, Installation
Service life 50 Years
Key Features
  • Attractive design with beautiful and elegant appearance using color steel sandwich panels
  • Lightweight construction for convenient shipping and handling
  • Easy assembly and dismantling with simple tools - can be rebuilt multiple times
  • Sturdy steel frame structure with sandwich panels for durability
  • Completely waterproof construction
  • Customizable roof, walls, doors, and windows to meet specific requirements
  • Long-lasting anti-corrosion coating on all steel components (50-year design life)
Technical Specifications
Main Structure Hot Dipped Galvanized Light Gauge Structure, H Section Steel
Storey 1-3 Storeys (customizable)
H Beam Dimensions Length: 1000-15000mm (custom)
Thickness: web plate 6-32mm, wing plate 6-40mm
Height: 200-1200mm
Color Options Custom painted finishes available
Building Size Custom width × length × eave height configurations
Main Components Foundation: Cement and steel basement bolts
Main frame: H section steel
Steel material: Q235, Q235B, Q345B or custom
Purlin: C or Z purlin (C120-C320, Z100-Z200)
Bracing: X-type or other types (angle, round pipe)
Bolts: Plain and high-strength options
Roof & Wall Sandwich panel or color corrugated steel sheet
Door Options Single door, sliding door, roll-up shutter door, walk door
Window Options Aluminium alloy windows
Surface Treatment Two layers of anti-rust painting or hot dip galvanized
Sheet Thickness 0.5mm or 0.6mm galvanized sheet
Accessories Semi-transparent skylight belts, ventilators, down pipe, galvanized gutter
Technology Processing: Bending, welding, decoiling, cutting, punching
Forming: Hot-rolled steel
Connection: Bolt connection
Performance Ratings Wind Resistance: Category 12
Earthquake Resistance: Category 10
HS Code 94069000
Advantages
  • Cost-effective solution with superior quality
  • High safety performance standards
  • Simple assembly and disassembly process
  • Manufactured under ISO9001 quality control system
  • Installation guidance from experienced engineers
  • Environmentally friendly, non-polluting construction
Applications
  • Factories and workshops
  • Warehouses and storage facilities
  • Hangars and garages
  • Poultry and livestock houses
  • Greenhouses
  • Steel web frame structures
  • Portal frame products
  • High-rise building projects
Customization Options
  • Crane options available (2-20Ton capacity)
  • OEM/ODM designs accepted
  • Standard seaworthy packing for container loading
Design Requirements

For custom designs, please provide:

  • Building dimensions (length, width, height, eave height, roof pitch)
  • Environmental factors (wind load, snow load, rain conditions, geological parameters)
  • Earthquake resistance requirements
  • Door and window specifications
  • Any special requests or additional information
Component Production
Prefab Steel Structure Warehouse Building with Sandwich Panels 0 Prefab Steel Structure Warehouse Building with Sandwich Panels 1 Prefab Steel Structure Warehouse Building with Sandwich Panels 2
Frequently Asked Questions
What is the derust grade for the steel components?
Main steel structure: ball blasting Sa 2.5. Secondary steel structure: manual derust St2.0.
How is the building installed?
We provide detailed construction drawings and manuals to guide step-by-step erection and installation.
What are the common types of industrial buildings?
Portal frame is widely used for workshops, offices, shopping malls and warehouses. Other types can be designed to meet specific needs.
How should the structure be maintained?
Painting touch-ups after installation will extend the surface protection. Regular inspections are recommended.
