Paint Galvanized FRP 1.5mm Q346B Steel Construction Warehouse
Product Attributes
| Attribute |
Value |
| Application |
Light Steel Structure Warehouse |
| Features |
Galvanized Metal Buildings |
| Type |
Steel Structure Warehouse |
| Working scope |
Design, Fabrication, Installation |
| Raw steel material |
Q235B, Q355B, ASTM A36 |
| Service life |
50 Years |
| Wall and Roof |
Steel cladding sheet |
| Surface treatment |
Painting |
Industrial Prefabricated Steel Warehouse Buildings
Product Type: Steel Structure Warehouse
Advantages of Steel Structure Buildings
- Light weight with greater resistance to earthquakes and strong winds
- Low maintenance costs with high-quality galvanized steel for sustainability
- Modular prefabrication shortens construction time
- Environmentally friendly with reusable steel components
- Flexible space utilization with repositionable walls
Steel Structure Building Applications
Widely used for warehouses, workshops, factories, hangars, exhibition halls, agricultural storage, and logistics centers.
Steel Structure Material Specifications
| Item |
Specification |
Material |
Treatment |
| Column |
H shape, Box, steel pipe, Hot rolled sheet |
Q235B, Q345B |
Paint or Hot dip galvanized |
| Beam |
H shape, steel Truss, Hot rolled sheet |
Q235B, Q345B |
Paint or Hot dip galvanized |
| Purling |
C or Z shape, thickness: 1.8mm~3.0mm |
Q235B, Q346B |
Hot dip galvanized |
| Wall/Roof panel |
EPS, Rock wool, Pu, Glass wool Sandwich panel |
Steel T=0.426~0.8mm, insulation T=50~150mm |
Alu-zinc 150g, Fluorocarbon paint |
| Door |
Sliding or rolling door |
Steel/Aluminum sheet, T=1.0~1.5mm |
Paint or Hot dip galvanized |
| Window |
Alloy-Glass, Aluminium alloy-shutter |
T=1.0~2.0mm |
Alloy |
| Lighting panel |
FRP, T=1.5mm or 1.8mm |
Coefficient of thermal expansion: 2.2x10-5/cm/cm/℃ |
Light transmittance 85% |
Key Product Features
- Low maintenance cost
- Environmentally friendly and recyclable
- Flexible door/window placement options
- Durable and stable construction
- Termite and pest resistant
- 50+ year service life
- Fast construction and easy installation
Steel Structure Production Process
Design: Custom engineering based on client requirements
Material: Preparation of raw materials per specifications
Cutting: Precision cutting of steel plates
Assembling: Spot welding of components
Auto welding: Full welding with arc-submerging machines
Straightening: Flattening of deformed components
Manual welding: Attachment of connection plates
Shot blasting: Surface rust removal
Painting: Antiseptic treatment
Delivery: Packaged and shipped to site
Erection: On-site assembly
Finishing: Project completion
