Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding

Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding
Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding
Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding

Large Image :  Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0229
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding

Description
Features: New Insulation Panel Prefab Steel Structure Warehouse Application: Panel Prefab Steel Structure Warehouse Buildings
Type: Steel Structure Warehouse Wall And Roof: Aluminized Zinc Cladding Sheet
Raw Steel Material: Q235B, Q355B Working Scope: Design,Fabrication, Installation
Surface Treatment: Painting Service Life: 50 Years
Highlight:

steel structure building

,

metal warehouse construction

,

Insulation Panel Prefab Steel Structure Warehouse

Insulation Panel Prefab Steel Structure Warehouse Buildings Modern Design
Product Specifications
Attribute Value
Application Panel Prefab Steel Structure Warehouse Buildings
Features New Insulation Panel Prefab Steel Structure Warehouse
Type Steel Structure Warehouse
Wall and Roof Aluminized zinc cladding sheet
Raw steel material Q235B, Q355B
Working scope Design, Fabrication, Installation
Surface treatment Painting
Service life 50 Years
Modern Design Prefab Steel Structure Warehouse

Our prefabricated steel structure warehouses incorporate advanced insulation materials including aluminum-zinc color plates, aluminum magnesium manganese plates, and aluminum-plastic plates. These materials provide:

  • Smooth, aesthetically pleasing appearance
  • Superior dustproof, antistatic, and antibacterial properties
  • Excellent sound absorption and fireproof performance
  • Factory prefabrication for standardized production and modular construction
  • Customizable designs to meet specific industry requirements
Technical Specifications
Structure Type Gable frame, single ridge, clean span or two spans
Length 40-100m
Width 20-80m
Eave Height 6-15m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof Material Aluminized zinc cladding sheet
Wall Material Aluminized zinc cladding sheet
Material List and Technical Parameters
Component Specification
Steel Frame H section steel | Q235/Q345 steel plate thickness: 8-30mm
Welding Automatic submerged arc welding
Surface finish Alkyd paint or galvanized
Roof Panel Sandwich panel or corrugated steel sheet
Wall Panel Sandwich panel or corrugated steel plate
Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding 0
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding 1
Advantages of Prefabricated Steel Structures
Light weight, high strength Steel offers exceptional strength-to-weight ratio, enabling large span structures with relatively small weight
Short construction period Factory prefabrication of components allows for rapid on-site assembly and installation
High fire resistance Fire-retardant coatings enhance fire endurance, with structural integrity maintained up to 150°C
Weather protection Specialized sealing techniques prevent water infiltration at joints and connections
Ventilation solutions Customizable ventilation systems including roof fans and exhaust systems for optimal air flow
Our Production Capabilities

Our 35,000㎡ fabrication facility includes 20,000㎡ of workshop space equipped with:

  • Three light/heavy H steel production lines
  • BOX production lines
  • C/Z purlin production lines
  • Advanced profiling steel sheet machines
  • Plasma cutting equipment
Insulated Prefab Steel Warehouse with Aluminized Zinc Cladding 2
