Pre Engineered Steel Structure Warehouse with 50-Year Lifespan

Pre Engineered Steel Structure Warehouse with 50-Year Lifespan
Pre Engineered Steel Structure Warehouse with 50-Year Lifespan
Pre Engineered Steel Structure Warehouse with 50-Year Lifespan Pre Engineered Steel Structure Warehouse with 50-Year Lifespan Pre Engineered Steel Structure Warehouse with 50-Year Lifespan Pre Engineered Steel Structure Warehouse with 50-Year Lifespan Pre Engineered Steel Structure Warehouse with 50-Year Lifespan Pre Engineered Steel Structure Warehouse with 50-Year Lifespan Pre Engineered Steel Structure Warehouse with 50-Year Lifespan

Large Image :  Pre Engineered Steel Structure Warehouse with 50-Year Lifespan

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0221
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Pre Engineered Steel Structure Warehouse with 50-Year Lifespan

Description
Features: Warehouse Structure Design Application: Pre Engineered Buildings,Steel Construction
Type: Steel Structure Warehouse Raw Steel Material: Q235B, Q355B
Working Scope: Design,Fabrication, Installation Surface Treatment: Painting
Service Life: 50 Years Wall And Roof: Steel Cladding Sheet
Highlight:

steel structure building

,

metal warehouse construction

,

100m Steel Construction Warehouse Structure

Durable Pre Engineered Buildings Steel Construction Warehouse Structure Design
Product Specifications
Application Pre engineered Buildings, Steel Construction
Features Warehouse Structure Design
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B
Working scope Design, Fabrication, Installation
Surface treatment Painting
Service life 50 Years
Wall and Roof Steel cladding sheet
Product Overview
We specialize in pre-engineered steel construction warehouse structures, offering comprehensive services from design to installation. Our steel structures combine durability with cost-efficiency, featuring short construction periods, high industrialization levels, and excellent resource reuse capabilities.
Structural Parameters
Structure Type Gable frame / portal frame, single ridge, clean span or two spans
Length 40-100m
Width 20-80m
Eave Height 6-15m
Roof Slope 10% ~ 15%
Gable Wall Column Spacing 7.5m
Roof Steel cladding sheet, sandwich panel
Wall Steel cladding sheet, sandwich panel
Door Sliding door, roller up door, etc.
Window Ribbon Skylight
Height difference between indoor and outdoor 300mm
Material Specifications
Item Specification Material Parameter Technical Treatment
Column H-section steel Q235B,Q345B Paint or Hot dip galvanized
Beam H-section steel Q235B,Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B,Q345B
Purlin C or Z shape, thickness: 1.8mm~3.0mm Q235B,Q346B Hot dip galvanized
Wall and roof panel EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet, T=1.0~1.5mm Paint or Hot dip galvanized
Window Alloy-Glass, Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion: 2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel, stainless steel, PC Paint or Hot dip galvanized, 304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized, 304
Downpipe PVC pipe, Color steel pipe T=0.5mm Φ110, 160, 200 Paint
Bolt Ordinary, high strength 10.9S, 4.8s Hot dip galvanized
Anchor bolt Steel rod M24, M27, M30 Q235B
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Designing, fabrication and installation for prefabricated steel structure buildings
  • Deepen or design fabrication drawings based on your architectural plans
  • Engineering consulting services
Pre Engineered Steel Structure Warehouse with 50-Year Lifespan 0
Production Capabilities
Our 35,000㎡ fabrication facility includes 20,000㎡ of workshop space equipped with three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines, and advanced profiling machines including plasma cutting equipment.
Pre Engineered Steel Structure Warehouse with 50-Year Lifespan 1
Packing & Loading
Pre Engineered Steel Structure Warehouse with 50-Year Lifespan 2
