Multi Span Steel Warehouse Building with Rock Wool Insulation

Multi Span Steel Warehouse Building with Rock Wool Insulation
Multi Span Steel Warehouse Building with Rock Wool Insulation
Multi Span Steel Warehouse Building with Rock Wool Insulation Multi Span Steel Warehouse Building with Rock Wool Insulation Multi Span Steel Warehouse Building with Rock Wool Insulation Multi Span Steel Warehouse Building with Rock Wool Insulation Multi Span Steel Warehouse Building with Rock Wool Insulation Multi Span Steel Warehouse Building with Rock Wool Insulation Multi Span Steel Warehouse Building with Rock Wool Insulation

Large Image :  Multi Span Steel Warehouse Building with Rock Wool Insulation

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0218
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Multi Span Steel Warehouse Building with Rock Wool Insulation

Description
Features: Light Metal Warehouse Construction Application: Multi Span Steel Frame Structure Warehouse Buildings
Type: Steel Structure Warehouse Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Rock Wool
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

steel structure building

,

metal warehouse construction

,

ASTM A36 Steel Structure Warehouse Buildings

Multi Span Steel Structure Warehouse Buildings Light Metal Warehouse Construction
Product Attributes
Attribute Value
Application Multi Span Steel Frame Structure Warehouse Buildings
Features Light Metal Warehouse Construction
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Rock wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Product Description
Multi Span Steel Frame Structure Warehouse Buildings / Light Metal Warehouse Construction. The portal steel frame steel structure workshop is mature in technology and widely used, which has become the fastest form of steel structure development. The portal-type steel frame steel structure workshop can be made into a large span and large space, which is convenient for flexible layout and use inside. (The steel structure workshop adopts the portal steel frame system, and its single span can even reach 80 meters. Multi-span can reach 180 meters or even longer.)
It is made of light H-shaped steel (welded or rolled; variable cross section or equal section) made of gate-shaped steel frame support, C-shaped, Z-shaped cold-formed thin-walled steel is used as purlins and wall beams, and profiled steel plates or lightweight sandwich plates are used as The roof and wall envelope structure is a door-type steel frame steel structure system assembled by using high-strength bolts, ordinary bolts and self-tapping screws and other connectors and sealing materials.
Steel structure workshops have been more reasonably and widely applied in the global scope, especially in developed countries and regions. Steel structure workshops can be widely used in industrial workshops, purification workshops, warehouses, supermarkets, hall exhibition halls.
Specification of Steel Structure Material
Main Parts Item Name Specification
Main Steel Frame Steel Column Q235B, Q345B
H shape, Box, Steel pipe, Hot rolled sheet
Steel Beam Q235B, Q345B
H shape, Steel Truss, Hot rolled sheet
Brace Q235B, Q345B
Steel rod, Steel pipe, Angle steel
Roof Purlin C or Z shape, Steel purlin
Supporting System Wall Purlin Q235B, Q345B
C or Z shape, Steel purlin
Roof Single colorful corrugate steel sheet, Sandwich panel with EPS, Rock wool, PU, Glass wool etc.
Supporting System Wall Single colorful corrugate steel sheet, Sandwich panel with EPS, Rock wool, PU, Glass wool etc.
Accessories Bolts Ordinary, High strength
Gutter Galvanized Steel plate, Stainless steel
Windows Aluminum alloy-Glass, Aluminum alloy-shutter, PVC
Doors Sliding or Rolling door
Downpipes PVC pipe, Color steel pipe
Edge Cover Made of color steel sheet thickness 0.5mm
Ventilator Stainless steel
Crane Crane in 5 tons to 30 tons
Our Service Scope for Steel Structure Project
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Designing, fabrication and installation for Prefabricated steel structure building
  • Deepen or design the fabrication drawing or shop drawing based on your architectural drawing and construction drawing
  • Engineering consulting service
Packing and Transport
All the structure components, panels, bolts and sort of accessories will be well packed with standard package suitable ocean transportation and loaded into 40'HQ.
All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers, who will prevent the goods to be damaged.
Multi Span Steel Warehouse Building with Rock Wool Insulation 0
How to Quote
The following question we need to know before making the price. Just feel free to fill what you know.
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
