Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified

Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified
Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified
Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified

Large Image :  Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV,ISO
Model Number: Ruly0216
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified

Description
Features: Steel Structure Warehouse With Floor Coat Application: Structural Steel Portal Frames
Type: Pre Manufactured Structural Steel Buildings Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Aluminum Composite Panel, Glass Wool Panel
Columns And Beam: H Section Column&Beam Standard: AISI, ASTM, BS, DIN, GB, JIS
Highlight:

steel structure building

,

metal storage buildings

,

SGS Structural Steel Portal Frames

Pre Manufactured Structural Steel Portal Frames With Floor Coat SGS Certification
Product Specifications
Attribute Value
Application Structural Steel Portal Frames
Features Steel Structure Warehouse With Floor Coat
Type Pre manufactured Structural Steel Buildings
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Aluminum composite panel, Glass wool panel
Columns and Beam H Section Column & Beam
Standard AISI, ASTM, BS, DIN, GB, JIS
Product Description
Pre manufactured Structural Steel Portal Frames Buildings With Floor Coat. A steel building is a metal structure fabricated with steel for the internal support and for exterior cladding, as opposed to steel framed buildings which generally use other materials for floors, walls, and external envelope. Steel buildings are used for a variety of purposes including storage, work spaces and living accommodation.
Installation
Project Manager is in charge of all the construction work on site.
Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified 0
Material Specifications
Component Specification
Frame H section steel | Q235/Q355 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace | L50x4, Steel Q235, processed and painted
Horizontal brace Φ20, Steel Q235, processed and painted
Column brace Φ20, Steel Q235, processed and painted
Tie rod Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof Purlin C160*60*2.5, Steel Q235, galvanized and painted
Roof panel Sandwich panel or corrugated steel sheet
Sky light 6mm thick PVC
Accessories Glass cement, self-tapping screws, etc.
Design Services
We provide Preliminary layout drawing, shop drawing, 3D Tekla model, and installation drawing for such projects.
Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified 1
Our Steel Structure Factory
Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified 2
Product Advantages
  • Wide span: Single span or Multi-span
  • Low cost: Unit price range from USD50/m² to USD90/m² according to clients' request
  • Long lifespan: About 30-50 years
  • Fast construction: Easy installation process
  • Additional benefits: Environmental protection, stable structure, earthquake resistance, water proofing, and energy conservation
Packing & Loading
All structure components, panels, bolts and accessories are well packed with standard packaging suitable for ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts at our factory loading site to prevent damage to goods during loading.
Pre Manufactured Steel Portal Frames With Floor Coat SGS Certified 3
Contact us today to discuss your project requirements!
