Product Details:
|
Features: | Light Steel Structure Warehouse | Application: | Manufacturer Of Structural Steel Buildings Warehouse |
---|---|---|---|
Type: | Prefab Steel Structure Warehouse | Raw Steel Material: | Q235B, Q355B, ASTM A36 |
Service Life: | 50 Years | Wall And Roof: | Steel Cladding Sheet |
Surface Treatment: | Painting | Working Scope: | Design,Fabrication, Installation |
Highlight: | steel structure building,metal warehouse construction,Q235B Steel Frame Buildings |
Attribute | Value |
---|---|
Application | Manufacturer Of Structural Steel Buildings Warehouse |
Features | Light Steel Structure Warehouse |
Type | Prefab Steel Structure Warehouse |
Raw steel material | Q235B, Q355B, ASTM A36 |
Service life | 50 Years |
Wall and Roof | Steel cladding sheet |
Surface treatment | Painting |
Working scope | Design, Fabrication, Installation |
Item name | Specification | Material Parameter | Technical Treatment |
---|---|---|---|
Column | H shaped steel | Q235B, Q345B | Paint or Hot dip galvanized |
Beam | H shaped steel | Q235B, Q345B | Paint or Hot dip galvanized |
Bracing | Steel rod, Steel pipe, Angle steel | Q235B, Q345B | |
Purling | C or Z shape, Thickness: 1.8mm~3.0mm | Q235B, Q346B | Hot dip galvanized |
Wall and roof panel | EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet | Steel T=0.426~0.8mm, insulation T=50~150mm | Alu-zinc 150g, Fluorocarbon paint |
Door | Sliding or rolling door | Steel or Aluminum sheet, T=1.0~1.5mm | Paint or Hot dip galvanized |
Window | Alloy-Glass, Aluminium alloy-shutter | T=1.0~2.0mm | Alloy |
Question | Details Needed |
---|---|
Location | _____country, area |
Size | _____mm*_____mm*_____mm |
Wind load | _____kn/m2, _____km/h, _____m/s |
Snow load | _____kn/m2, _____mm |
Anti-earthquake | _____level |
Brickwall needed | If yes, 1.2m high or 1.5m high |
Thermal insulation | If yes, specify material: EPS, fiberglass wool, rockwool, PU sandwich panels |
Contact Person: steven
Tel: 0086-18661691560
