Steel Structure Warehouse Prefabricated Metal Frame Building

Steel Structure Warehouse Prefabricated Metal Frame Building
Steel Structure Warehouse Prefabricated Metal Frame Building
Steel Structure Warehouse Prefabricated Metal Frame Building Steel Structure Warehouse Prefabricated Metal Frame Building Steel Structure Warehouse Prefabricated Metal Frame Building Steel Structure Warehouse Prefabricated Metal Frame Building Steel Structure Warehouse Prefabricated Metal Frame Building Steel Structure Warehouse Prefabricated Metal Frame Building Steel Structure Warehouse Prefabricated Metal Frame Building

Large Image :  Steel Structure Warehouse Prefabricated Metal Frame Building

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0207
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: Steel frame pallets and loaded into 40’HQ
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Steel Structure Warehouse Prefabricated Metal Frame Building

Description
Application: Prefabricated Warehouse Buildings In Steel Shot Blasting Level: Metal Frame Structure Warehouse
Type: Steel Structure Warehouse Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Rock Wool
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Columns & Beams: H-section Steel Standard: AISC, ASTM, BS, DIN, GB, JIS
Highlight:

metal warehouse construction

,

metal storage buildings

,

Q235B Steel Prefabricated Warehouse Buildings

Metal Frame Structure Warehouse / Prefabricated Warehouse Buildings In Steel
Product Specifications
Attribute Value
Application Prefabricated Warehouse Buildings In Steel
Shot blasting level Metal Frame Structure Warehouse
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Rock wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Columns & Beams H-section steel
Standard AISC, ASTM, BS, DIN, GB, JIS
Product Overview

Our Metal Frame Structure Warehouse offers superior strength and durability compared to concrete and wood structures. With higher yield point and tensile strength, steel structural members feature smaller cross-sections and lighter weight, facilitating easier transportation and installation while maximizing interior space.

Technical Specifications
Component Specification
Main Steel Frame (Column) Q235, Q345 Welded H Section Steel
Main Steel Frame (Beam) Q235, Q345 Welded H Section Steel
Secondary Frame (Purlin) Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Window Aluminium Alloy Window / PVC Window / Sandwich Panel Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Live load on Roof 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
Temperature Range -50°C to +50°C
Certification CE, SGS, ISO9001:2008, ISO14001:2004
Finishing Options Vast array of colors and textures available
Paint Options Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) or Galvanized
Steel Structure Warehouse Prefabricated Metal Frame Building 0
Manufacturing Capabilities

Our 35,000㎡ steel structure fabrication facility includes 20,000㎡ of workshop space equipped with advanced production lines for light/heavy H steel, BOX sections, C/Z purlins, and profiling steel sheet machines, including plasma cutting technology.

Steel Structure Warehouse Prefabricated Metal Frame Building 1
Installation Services

We provide detailed construction drawings prior to installation and can dispatch our engineers for on-site guidance or complete the installation with our professional construction team.

Steel Structure Warehouse Prefabricated Metal Frame Building 2
