Product Details:
|
Features: | Prefab Metal Warehouse Building Construction | Application: | Steel Frame Storage Buildings |
---|---|---|---|
Type: | Prefab Steel Buildings | Raw Steel Material: | Q235B, Q355B, ASTM A36 |
Service Life: | 50 Years | Wall And Roof: | Rock Wool |
Surface Treatment: | Painting | Working Scope: | Design,Fabrication, Installation |
Columns & Beams: | H-section Steel | Standard: | AISC, ASTM, BS, DIN, GB, JIS |
Highlight: | steel structure building,metal storage buildings,Q235B Steel Frame Storage Buildings |
Attribute | Value |
---|---|
Application | Steel Frame Storage Buildings |
Features | Prefab Metal Warehouse Building Construction |
Type | Prefab Steel Buildings |
Raw steel material | Q235B, Q355B, ASTM A36 |
Service life | 50 Years |
Wall and Roof | Rock wool |
Surface treatment | Painting |
Working scope | Design, Fabrication, Installation |
Columns & Beams | H-section steel |
Standard | AISC, ASTM, BS, DIN, GB, JIS |
Our high-strength steel frame storage buildings offer prefabricated metal warehouse construction solutions. These structures utilize a series of steel components including columns, beams, and purlins to create durable, cost-efficient warehouse spaces with a lightweight design that simplifies construction.
Component | Specification |
---|---|
Main Steel Frame (Column) | Q235, Q345 Welded H Section Steel |
Main Steel Frame (Beam) | Q235, Q345 Welded H Section Steel |
Secondary Frame (Purlin) | Q235 C and Z purlin |
Knee brace | Q235 Angle Steel |
Tie Rod | Q235 Circular Steel Pipe |
Brace | Q235 Round Bar |
Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe |
Roof Panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet |
Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
Window | Aluminium Alloy Window / PVC Window / Sandwich Panel Window |
Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
Rainspout | PVC |
Live load on Roof | 120kg/Sqm (Color steel panel surrounded) |
Wind Resistance Grade | 12 Grades |
Earthquake-resistance | 8 Grades |
Structure Usage | Up to 50 years |
Temperature Range | -50°C to +50°C |
Certification | CE, SGS, ISO9001:2008, ISO14001:2004 |
Finishing Options | Vast array of colors and textures available |
Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized |
Our 35,000㎡ steel structure fabrication facility includes 20,000㎡ of workshop space equipped with three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines, and advanced equipment including plasma cutting machines.
We provide detailed construction drawings for each project and can dispatch engineers to guide on-site installation or complete the installation with our professional construction team.
All structural components, panels, bolts, and accessories are packed to withstand ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to load goods at our factory, ensuring damage-free transport.
