Prefab Steel Structure Warehouse with Glass Wool Insulation

Prefab Steel Structure Warehouse with Glass Wool Insulation
Prefab Steel Structure Warehouse with Glass Wool Insulation
Prefab Steel Structure Warehouse with Glass Wool Insulation Prefab Steel Structure Warehouse with Glass Wool Insulation Prefab Steel Structure Warehouse with Glass Wool Insulation Prefab Steel Structure Warehouse with Glass Wool Insulation Prefab Steel Structure Warehouse with Glass Wool Insulation Prefab Steel Structure Warehouse with Glass Wool Insulation Prefab Steel Structure Warehouse with Glass Wool Insulation

Large Image :  Prefab Steel Structure Warehouse with Glass Wool Insulation

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0175
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Warehouse with Glass Wool Insulation

Description
Application: Metal Buildings, Steel Frame Structure, Metal Warehouse Type: Prefab Steel Buildings
Usage: Steel Structure Warehouse Raw Steel Material: Q235B, Q355B, ASTM A36
Shot Blasting Level: Sa 2.5 Wall And Roof: Glass Wool
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

steel structure building

,

metal storage buildings

,

Prefab Metal Building Framing Components

Prefab Metal Building Framing Components
Product Specifications
Application Metal buildings, Steel Frame Structure, Metal Warehouse
Type Prefab Steel Buildings
Usage Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Shot blasting level Sa 2.5
Wall and Roof Glass wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Product Description
Our prefabricated steel structure warehouse systems consist of high-quality steel components including columns, beams, and purlins that form a durable load-bearing structure. These lightweight yet strong buildings offer cost-efficient solutions for various industrial applications with easy construction and excellent performance.
Technical Parameters
Steel Frame H section steel | Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Horizontal brace: Φ20, Steel Q235, processed and painted
Column brace: Φ20, Steel Q235, processed and painted
Tie rod: Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Accessories: Glass cement, self-tapping screws, etc.
Edge cover: 0.4mm steel sheet profile trimming
Walls Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Accessories: Glass cement, self-tapping screws, etc.
Edge cover: 0.4mm steel sheet profile trimming
Our Advantages
Professional design team Custom designs based on your requirements or calculations from your drawings
Skilled fabrication Independent production schedules with pre-project training for workers
One-stop service Integrated project proposals for customized steel structures
Quality control Professional QC team ensures products meet specifications
After-sales service Maintenance support for insulation and steel components
Manufacturing Capabilities
Our factory features three production lines with advanced equipment including plasma cutting machines for precise steel fabrication.
Prefab Steel Structure Warehouse with Glass Wool Insulation 0
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel buildings
  • Shop drawing development from architectural plans
  • Engineering consulting services
Prefab Steel Structure Warehouse with Glass Wool Insulation 1
Installation Support
We provide detailed construction drawings for each project and can send engineers to guide installation at your site.
Prefab Steel Structure Warehouse with Glass Wool Insulation 2
Quotation Requirements
Please provide the following information for an accurate quote:
Location Country and area where building will be constructed
Size Length × width × height (in mm)
Wind load Maximum wind speed (kn/m², km/h, or m/s)
Snow load Maximum snow height (kn/m² or mm)
Earthquake resistance Required seismic level
Brick walls If needed: 1.2m or 1.5m height
Thermal insulation Material preference: EPS, fiberglass wool, rockwool, PU sandwich panels, or metal sheets
Doors Quantity and dimensions (width × height in mm)
Windows Quantity and dimensions (width × height in mm)
Crane requirements If needed: quantity, maximum lifting weight (tons), and height (m)
