Q235B Q355B Light Steel Structure Warehouse Framing

Q235B Q355B Light Steel Structure Warehouse Framing
Q235B Q355B Light Steel Structure Warehouse Framing Q235B Q355B Light Steel Structure Warehouse Framing Q235B Q355B Light Steel Structure Warehouse Framing Q235B Q355B Light Steel Structure Warehouse Framing Q235B Q355B Light Steel Structure Warehouse Framing Q235B Q355B Light Steel Structure Warehouse Framing Q235B Q355B Light Steel Structure Warehouse Framing

Large Image :  Q235B Q355B Light Steel Structure Warehouse Framing

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0174
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month

Q235B Q355B Light Steel Structure Warehouse Framing

Description
Application: Structural Steel Framing, Light Steel Structure Warehouse Shot Blasting Level: Metal Warehouse, Prefab Steel Buildings
Type: Steel Frame Structure, Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Glass Wool
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

metal warehouse construction

,

metal storage buildings

,

Q355B Material Steel Structure Warehouse

Structural Steel Framing / Q235B / Q355B Material Light Steel Structure Warehouse
Product Specifications
Attribute Value
Application Structural Steel Framing, Light Steel Structure Warehouse
Shot blasting level Metal Warehouse, Prefab Steel Buildings
Type Steel Frame Structure
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Glass wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Project Overview

With the rapid development of industrial construction, steel structure warehouses and workshop buildings have become widely adopted due to their significant advantages: light weight, high strength, large span capability, and environmental friendliness.

The structural system consists of:

  • Transverse structure: Trusses (roof trusses, beams, and columns) that bear roof loads, lateral wind/earthquake forces, and crane vertical/horizontal loads
  • Longitudinal structure: Columns, inter-column supports, and wall beams forming a space rigid skeleton with peripheral wall frames and roof supports
Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235 | Horizontal brace: Φ20, Steel Q235 | Column brace: Φ20, Steel Q235 | Tie rod: Φ89*3, Steel Q235
Ordinary bolt M12 Galvanized bolt
Roof System Purlin: C160*60*2.5, Steel Q235 | Roof panel: Sandwich panel or corrugated steel sheet
Wall System Purlin: C160*60*2.5, Steel Q235 | Wall: Sandwich panel or corrugated steel plate
Manufacturing Process

Qingdao Ruly Steel Engineering Co., Ltd specializes in steel structure fabrication and construction for both light and heavy steel structures, offering comprehensive design, manufacture, and installation services.

Our advanced production facilities include:

  • Three dedicated steel structure production lines
  • State-of-the-art equipment including plasma cutting machines
Q235B Q355B Light Steel Structure Warehouse Framing 0
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Fabrication drawing development based on architectural plans
  • Professional engineering consulting services
Q235B Q355B Light Steel Structure Warehouse Framing 1
Packaging & Shipping

All structural components, panels, bolts, and accessories are securely packed for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to ensure damage-free loading at our factory.

Q235B Q355B Light Steel Structure Warehouse Framing 2
Quotation Requirements

Please provide the following information for an accurate quote:

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be used
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
