Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life

Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life
Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life
Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life

Large Image :  Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV，ISO
Model Number: Ruly0172
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life

Description
Application: Steel Structure Warehouse, Steel Prefab Buildings Type: Prefab Steel Buildings
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting Or Hot-dip Galvanize
Shot Blasting Level: Sa 2.5 Service Life: 50 Years
Wall And Roof: Glass Wool Sandwich Panel Working Scope: Design,Fabrication, Installation
Highlight:

steel structure building

,

metal storage buildings

,

150m Prefab Steel Structure Warehouse

Prefabricated Steel Structure Warehouse / Steel Prefab Buildings Contractors
Product Specifications
Attribute Value
Application Steel structure warehouse, Steel Prefab Buildings
Type Prefab Steel Buildings
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Glass wool sandwich panel
Working scope Design, Fabrication, Installation
Product Overview

Our prefabricated steel structure warehouses are engineered for durability and efficiency. These steel buildings feature a single ridge and two spans design, with load-bearing components including steel columns, beams, foundations, and roof trusses.

Key advantages include:

  • Simple yet robust design structure
  • Lightweight with high strength-to-weight ratio
  • Streamlined production and installation process
  • Large span capabilities for spacious interiors
  • Short construction timeline
  • Cost-effective solution
  • Excellent earthquake resistance
Project Specifications
Parameter Specification
Structure Type Portal frame, single ridge, double spans
Length Scope 20-150m
Width Scope 20-80m
Eave Height 9-20m
Roof Slope Portal frame or gable frame
Gable Wall Column Spacing 7.5m
Roof Material Glass wool sandwich panel
Wall Material Glass wool sandwich panel
Door Type Sliding door
Window Type Ribbon Skylight
Height difference (indoor/outdoor) 300mm
Technical Components
Main Steel Frame System:
  • Main structure: H section steel Q355 with alkyd painting (2 primary, 2 finish coats)
  • Roof purlin: XZ160*60*20*2.5, galvanized
  • Wall purlin: XZ160*60*20*2.5, galvanized
  • Fasteners: Grade 10.9 intensive bolts, M20+2 turn buckle bolts, M24 anchor bolts
Bracing System:
  • Cross brace: Φ20 round steel bar Q235
  • Angle brace: L50*5 angle steel Q235
  • Column bracing: Φ25 round steel bar Q235
  • Tie bar: Φ127*3 steel pipe Q235
  • Batter brace: Φ32*2.5, Φ12 round steel bar Q235
Wall & Roof System:
  • Roof and wall panels: Glass wool sandwich panel
  • Edge cover: 0.5mm color plate with aluminum angle
  • Ventilation: Φ600 stainless steel unpowered ventilator
  • Lighting: 1.2mm FRP skylight band (double layer)
  • Drainage: 0.5mm color steel gutter with Φ110 PVC rainspout
Manufacturing Capabilities

Qingdao Ruly Steel Engineering Co., Ltd operates a 35,000㎡ facility with 20,000㎡ of workshop space. Our advanced production lines include:

  • Light/heavy H steel production lines
  • BOX production lines
  • C/Z purlin production lines
  • Profiling steel sheet machines
  • Plasma cutting equipment
Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life 0
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life 1
Packaging & Shipping

All components are packed for secure ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to prevent damage during loading.

Prefab Steel Structure Warehouse with Glass Wool Panels 50 Years Life 2
Request a Quote

Please provide the following information for an accurate quotation:

Item Details Required
1 Project location (country, area)
2 Building dimensions (length × width × height in mm)
3 Maximum wind load (kn/m², km/h, or m/s)
4 Maximum snow load (kn/m² or mm)
5 Earthquake resistance level required
6 Brickwall requirements (height if needed)
7 Thermal insulation specifications
8 Door quantity and dimensions
9 Window quantity and dimensions
10 Crane requirements (quantity, capacity, height)
