Prefab Light Span Steel Warehouse with Truss Roof

Prefab Light Span Steel Warehouse with Truss Roof
Prefab Light Span Steel Warehouse with Truss Roof
Prefab Light Span Steel Warehouse with Truss Roof Prefab Light Span Steel Warehouse with Truss Roof Prefab Light Span Steel Warehouse with Truss Roof Prefab Light Span Steel Warehouse with Truss Roof Prefab Light Span Steel Warehouse with Truss Roof Prefab Light Span Steel Warehouse with Truss Roof Prefab Light Span Steel Warehouse with Truss Roof

Large Image :  Prefab Light Span Steel Warehouse with Truss Roof

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0164
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Light Span Steel Warehouse with Truss Roof

Description
Features: Truss Roof Metal Storage Buildings Application: Light Span Steel Structures
Type: Prefab Steel Buildings Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Service Life: 50 Years
Wall And Roof: Glass Wool Working Scope: Design,Fabrication, Installation
Highlight:

steel structure building

,

metal warehouse construction

,

Truss Roof Metal Storage Buildings

Light Span Steel Structures Warehouse / Truss Roof Metal Storage Buildings
Product Specifications
Attribute Value
Application Light Span Steel Structures
Features Truss Roof Metal Storage Buildings
Type Prefab Steel Buildings
Raw steel material Q235B, Q355B
Surface treatment Painting
Service life 50 Years
Wall and Roof Glass wool
Working scope Design, Fabrication, Installation
Project Overview

Our Light Span Steel Structures Warehouse with Truss Roof Metal Storage Buildings are designed for parking engineering vehicles and storing goods. The main steel frame structure consists of light steel columns and truss beams connected by high-strength bolts, providing large interior space and easy installation.

Technical Parameters
Component Specification Details
Steel Frame H section steel Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace L50x4, Steel Q235, processed and painted
Horizontal brace Φ20, Steel Q235, processed and painted
Column brace Φ20, Steel Q235, processed and painted
Tie rod Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof Purlin C160*60*2.5, Steel Q235, galvanized and painted
Roof panel Sandwich panel or corrugated steel sheet
Sky light 6mm thick PVC
Walls Purlin C160*60*2.5, Steel Q235, painted
Wall Sandwich panel or corrugated steel plate
Our Competitive Advantages
Advantage Description
Professional design team Custom drawings based on your requirements or steel quantity calculations from your drawings
Skilled fabrication Independent production schedules for each project with pre-fabrication training
One-stop service Customized solutions with integrated project proposals
Quality control Professional QC team ensures products meet specifications
After-sales service Maintenance support for insulation and steel components
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Design, fabrication and installation of prefabricated steel structures
  • Shop drawing development from architectural plans
  • Engineering consulting services
Prefab Light Span Steel Warehouse with Truss Roof 0
Quotation Requirements
Item Details Needed
Location Country and area where building will be constructed
Size Length × width × height (in mm)
Wind load Maximum wind speed (kn/m², km/h, or m/s)
Snow load Maximum snow height (kn/m² or mm)
Earthquake resistance Required seismic level
Brick wall If needed: 1.2m or 1.5m height
Thermal insulation Type: EPS, fiberglass wool, rockwool, PU sandwich panels, or none
Doors Quantity and dimensions (width × height in mm)
Windows Quantity and dimensions (width × height in mm)
Crane If needed: quantity, max lifting weight (tons), and height (m)
