Product Details:
|
Features: | Steel Structure Warehouse | Application: | Prefab Metal Building, Light Steel Framing Structure |
---|---|---|---|
Type: | Portal Frame Steel Warehouse | Raw Steel Material: | Q235B, Q355B |
Surface Treatment: | Painting | Service Life: | 50 Years |
Wall And Roof: | Sandwich Panel | Working Scope: | Design,Fabrication, Installation |
Highlight: | steel structure building,metal warehouse construction |
Attribute | Value |
---|---|
Application | Prefab Metal Building, Light Steel Framing Structure |
Features | Steel Structure Warehouse |
Type | Portal Frame Steel Warehouse |
Raw steel material | Q235B, Q355B |
Surface treatment | Painting |
Service life | 50 Years |
Wall and Roof | Sandwich panel |
Working scope | Design, Fabrication, Installation |
Component | Specification | Material/Process |
---|---|---|
Main steel frame | H-section steel | Q345 steel 8mm to 10mm |
Welding | Automatic Submerged Arc Welding | |
Rust removing | Sand blasting | |
Surface processing | Alkyd Paint or galvanized | |
High strength bolt | Grade 10.9 | |
Supporting system | Angle brace | L50x4, Steel Q235, Process and painting |
Cross bracing | dia.20 round bar | Steel Q235, process and painting |
Tie bar | dia.89*3 round pipe | Steel Q235 Process and painting |
Batter brace | dia.12 round bar | Steel Q235 process and painting |
Ordinary bolt | Galvanized bolt | |
Roof Purlin | C160*60*2.5 | steel Q235, Painting or galvanized |
Out-roof panel | Sandwich panel or corrugated steel plate | |
Transparent skylight | 6mm thick PVC | |
Accessories | Sealant, self-tapping screw, etc. | |
Edge cover | Made of color steel sheet thickness 0.5mm |
Item | Details Required |
---|---|
Location | Country, area where building will be constructed |
Size | Length × width × height (mm) |
Wind load | Maximum wind speed (kn/m², km/h, or m/s) |
Snow load | Maximum snow height (kn/m² or mm) |
Anti-earthquake | Required earthquake resistance level |
Brickwall | If needed: 1.2m high or 1.5m high |
Thermal insulation | If required: EPS, fiberglass wool, rockwool, or PU sandwich panels |
Door specifications | Quantity and dimensions (width × height in mm) |
Window specifications | Quantity and dimensions (width × height in mm) |
Crane requirements | If needed: quantity, maximum lifting weight (tons), and lifting height (m) |
