Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B

Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B
Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B
Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B

Large Image :  Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0128
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B

Description
Application: Metal Horse Sheds, Cowshed Steel Frame Structure Stable Type: Metal Shed
Featurs: Steel Structure Warehouse Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Service Life: 50 Years
Wall And Roof: Sandwich Panel Working Scope: Design,Fabrication, Installation
Highlight:

metal warehouse construction

,

metal storage buildings

Cowshed Steel Frame Metal Horse Shed Structure Stable Buildings Construction
Product Specifications
Attribute Value
Application Metal Horse Sheds, Cowshed Steel Frame Structure Stable
Type Metal Shed
Features Steel Structure Warehouse
Raw steel material Q235B, Q355B
Surface treatment Painting
Service life 50 Years
Wall and Roof Sandwich panel
Working scope Design, Fabrication, Installation
Project Overview

Our Cowshed Steel Frame Metal Horse Shed Structure provides durable construction for animal housing. Designed as feeding sheds for horses and cows, these structures offer superior strength and functionality compared to traditional concrete buildings.

Structural Components
Component Specification Material/Process
Steel Frame H section steel Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20 Grade 10.9
Supporting System Angle brace L50x4, Steel Q235, processed and painted
Horizontal brace Φ20 Steel Q235, processed and painted
Column brace Φ20 Steel Q235, processed and painted
Tie rod Φ89*3 Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof Purlin C160*60*2.5, Steel Q235, galvanized and painted
Roof panel Sandwich panel or corrugated steel sheet
Sky light 6mm thick PVC
Accessories Glass cement, self-tapping screws, etc.
Production Capabilities

Our 35,000㎡ fabrication facility includes 20,000㎡ of workshop space equipped with:

  • Three light/heavy H steel production lines
  • BOX production lines
  • C/Z purlin production lines
  • Advanced profiling steel sheet machines
  • Plasma cutting equipment
Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B 0
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Design, fabrication and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Engineering consulting services
Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B 1
Packaging and Shipping

All components are carefully packed for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to ensure safe loading at our factory.

Steel Frame Cowshed Metal Horse Stable Structure Q235B Q355B 2
Quotation Requirements

Please provide the following information for an accurate quote:

Item Details Required
1 Location (where will be built?)
2 Size: length*width*height
3 Wind load (max. wind speed)
4 Snow load (max. snow height)
5 Anti-earthquake requirements
6 Brickwall needed (height if yes)
7 Thermal insulation requirements
8 Door quantity & size
9 Window quantity & size
10 Crane requirements (if needed)
