Prefab Steel Warehouse Building with Sandwich Panel Walls

Prefab Steel Warehouse Building with Sandwich Panel Walls
Prefab Steel Warehouse Building with Sandwich Panel Walls
Prefab Steel Warehouse Building with Sandwich Panel Walls Prefab Steel Warehouse Building with Sandwich Panel Walls Prefab Steel Warehouse Building with Sandwich Panel Walls Prefab Steel Warehouse Building with Sandwich Panel Walls Prefab Steel Warehouse Building with Sandwich Panel Walls Prefab Steel Warehouse Building with Sandwich Panel Walls Prefab Steel Warehouse Building with Sandwich Panel Walls

Large Image :  Prefab Steel Warehouse Building with Sandwich Panel Walls

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0109
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Warehouse Building with Sandwich Panel Walls

Description
Features: Steel Structure Warehouse Application: Low Cost Prefabricated Buildings
Type: Prefab Steel Buildings Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Service Life: 50 Years
Wall And Roof: Sandwich Panel Working Scope: Design,Fabrication, Installation
Highlight:

steel structure building

,

metal warehouse construction

Low Cost Prefabricated Light Weight Buildings For Steel Structure Warehouse
Product Specifications
Attribute Value
Application Low Cost Prefabricated Buildings
Features Steel Structure Warehouse
Type Prefab Steel Buildings
Raw steel material Q235B, Q355B
Surface treatment Painting
Service life 50 Years
Wall and Roof Sandwich panel
Working scope Design, Fabrication, Installation
Project Overview
This prefabricated steel structure warehouse is designed for storing automobile motors. With the rapid development of industrial construction, steel structure warehouses and workshops have become widely adopted due to their significant advantages: light weight, high strength, large span capability, and environmental friendliness.
Structural Details
Specification Value
Structure Type Portal frame, double ridges, two spans for each ridge
Length 200m
Width 120m
Eave Height 10m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof & Wall insulation panel 75mm Glass wool sandwich panel
Door Sliding door
Window Ribbon Skylight
Material Specifications
Component Material Specification
Steel Column Q235B, Q345B H shape, Box, Steel pipe, Hot rolled sheet
Steel Beam Q235B, Q345B H shape, Steel Truss, Hot rolled sheet
Brace Q235B, Q345B Steel rod, Steel pipe, Angle steel
Roof Purlin C or Z shape, Steel purlin
Wall Purlin Q235B, Q345B C or Z shape, Steel purlin
Roof Single colorful corrugate steel sheet, Sandwich panel with EPS, Rock wool, PU, Glass wool
Wall Single colorful corrugate steel sheet, Sandwich panel with EPS, Rock wool, PU, Glass wool
Production Capabilities
We operate three production lines for steel structure fabrication, equipped with advanced machinery including plasma cutting machines to ensure high-quality output for international projects.
Prefab Steel Warehouse Building with Sandwich Panel Walls 0
Our Services
We provide customized design and fabrication services for both light and heavy steel structure buildings in portal frame and dome frame configurations. Our expertise includes:
  • Warehouses and workshops
  • Storage facilities and hangars
  • Agricultural buildings (chicken sheds, etc.)
  • Commercial structures (markets, supermarkets, parking facilities)
  • Industrial buildings (factories, plants)
  • Public buildings (exhibition halls, gyms, dormitories)
  • Specialized structures (power stations, infrastructure buildings)
Prefab Steel Warehouse Building with Sandwich Panel Walls 1
Packaging and Shipping
All structural components, panels, bolts, and accessories are carefully packed using standard ocean transportation packaging. Our skilled workers use cranes and forklifts to load products at our factory, ensuring safe transport and preventing damage.
Prefab Steel Warehouse Building with Sandwich Panel Walls 2
Request a Quote
Please provide the following information for an accurate quotation:
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, the metal steel sheets will be ok
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
