Prefab Steel Structure Warehouse with Large Span Q235B Q355B

Prefab Steel Structure Warehouse with Large Span Q235B Q355B
Prefab Steel Structure Warehouse with Large Span Q235B Q355B
Prefab Steel Structure Warehouse with Large Span Q235B Q355B Prefab Steel Structure Warehouse with Large Span Q235B Q355B Prefab Steel Structure Warehouse with Large Span Q235B Q355B Prefab Steel Structure Warehouse with Large Span Q235B Q355B Prefab Steel Structure Warehouse with Large Span Q235B Q355B Prefab Steel Structure Warehouse with Large Span Q235B Q355B Prefab Steel Structure Warehouse with Large Span Q235B Q355B

Large Image :  Prefab Steel Structure Warehouse with Large Span Q235B Q355B

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0092
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Warehouse with Large Span Q235B Q355B

Description
Features: Large Span Steel Structure Warehouse Application: Steel Frame Structure Logistics Warehouse Buildings
Type: Prefab Steel Structure Warehouse Raw Steel Material: Q235B, Q355B, ASTM A36
Service Life: 50 Years Wall And Roof: Steel Cladding Sheet
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Highlight:

steel structure building

,

metal storage buildings

,

Q235B Steel Frame Structure Logistics Warehouse

Steel Frame Structure Logistics Warehouse Buildings With Large Span
Product Attributes
Application
Steel Frame Structure Logistics Warehouse Buildings
Features
Large Span Steel Structure Warehouse
Type
Prefab Steel Structure Warehouse
Raw steel material
Q235B, Q355B, ASTM A36
Service life
50 Years
Wall and Roof
Steel cladding sheet
Surface treatment
Painting
Working scope
Design, Fabrication, Installation
Product Description

Our steel frame structure logistics warehouse buildings feature large spans, combining light weight with high strength. The steel construction allows for expansive spaces ideal for logistics operations while maintaining structural integrity.

As a general contractor for prefabricated steel structures, we provide comprehensive services including design, fabrication of primary and secondary steel components, and professional installation.

Specification of Steel Structure Logistics Warehouse
Item name Specification Material Parameter Technical Treatment
Column H shaped steel Q235B,Q345B Paint or Hot dip galvanized
Beam H shaped steel Q235B,Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B,Q345B
Purling C or Z shape, purling Thickness:1.8mm~3.0mm Q235B,Q346B Hot dip galvanized
Wall and roof panel EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet, T=1.0~1.5mm Paint or Hot dip galvanized
Window alloy-Glass, Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion:2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel, stainless steel, PC Paint or Hot dip galvanized,304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized,304
Downpipe PVC pipe, Color steel pipe T=0.5mm Φ110,160,200 Paint
Bolt Ordinary, high strength 10.9S,4.8s Hot dip galvanized
Anchor bolt Steel rod M24,M27 M30 Q235B
Our Steel Structure Production Line

All components are precision-manufactured in our specialized metal structure factory, ensuring high quality and dimensional accuracy. The prefabricated elements are then efficiently assembled on-site, significantly reducing construction time.

Prefab Steel Structure Warehouse with Large Span Q235B Q355B 0
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Installation Process

We provide comprehensive construction drawings for each project and can dispatch engineers to guide on-site installation or manage the entire construction process for international projects.

Prefab Steel Structure Warehouse with Large Span Q235B Q355B 1
Quotation Requirements

To provide an accurate quote, we require the following information:

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
