Prefabricated Steel Warehouse Building Multi Span Q235B Q355B

Prefabricated Steel Warehouse Building Multi Span Q235B Q355B
Prefabricated Steel Warehouse Building Multi Span Q235B Q355B
Prefabricated Steel Warehouse Building Multi Span Q235B Q355B Prefabricated Steel Warehouse Building Multi Span Q235B Q355B Prefabricated Steel Warehouse Building Multi Span Q235B Q355B Prefabricated Steel Warehouse Building Multi Span Q235B Q355B Prefabricated Steel Warehouse Building Multi Span Q235B Q355B Prefabricated Steel Warehouse Building Multi Span Q235B Q355B Prefabricated Steel Warehouse Building Multi Span Q235B Q355B

Large Image :  Prefabricated Steel Warehouse Building Multi Span Q235B Q355B

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0068
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Warehouse Building Multi Span Q235B Q355B

Description
Application: Prefabricated Steel Structure Warehouse Buildings Type: Multi Span Buildings Construction
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting Or Hot-dip Galvanize
Shot Blasting Level: Sa 2.5 Service Life: 50 Years
Wall And Roof: Glass Wool Working Scope: Design,Fabrication, Installation
Highlight:

metal warehouse construction

,

metal storage buildings

,

Prefabricated Steel Structure Warehouse Buildings

Prefabricated Steel Structure Warehouse Buildings Multi Span Buildings Construction
Product Attributes
Attribute Value
Application Prefabricated Steel Structure Warehouse Buildings
Type Multi Span Buildings Construction
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Glass wool
Working scope Design, Fabrication, Installation
Product Description

This prefabricated steel structure warehouse building is designed for electric appliance products storage and features electric overhead cranes in selected spans.

Key advantages over traditional concrete buildings include:

  • Lightweight construction reducing foundation costs
  • Faster construction speed enabling quicker operational readiness
  • Superior economic benefits compared to concrete structures
Project Specifications
Structure Type Portal frame, multi ridge, multi spans
Dimensions Length: 200m | Width: 120m | Eave Height: 12m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof & Wall Material 75mm thick Rock wool sandwich panel
Door & Window Sliding door | Ribbon Skylight
Height Difference 300mm between indoor and outdoor
Structural Components & Technical Parameters
Main Steel Frame System
Main structure H section steel Q355, alkyd painting (two primary, two finish coats)
Roof & Wall purlin XZ160*60*20*2.5, galvanized
Fasteners Grade 10.9 intensive bolts, M20+2 turn buckle bolts (Q235), M24 anchor bolts (Q235)
Bracing System
Cross brace Φ20 round steel bar Q235, painted
Angle brace L50*5 angle steel Q235, painted
Column bracing Φ25 round steel bar Q235, painted
Wall & Roof System
Panels 75mm thick Rock wool sandwich panels
Ventilation Φ600 stainless steel unpowered ventilator
Lighting 1.2mm FRP double layer skylight band
Our Production Facility
Prefabricated Steel Warehouse Building Multi Span Q235B Q355B 0
Packaging & Transportation

All structural components, panels, bolts, and accessories are packed in standard ocean transportation containers (40'HQ). Our skilled workers use cranes and forklifts to ensure damage-free loading at our factory.

Prefabricated Steel Warehouse Building Multi Span Q235B Q355B 1
