Steel Structure Warehouse Workshop Q235B Q355B 50 Years Life

Our steel structure warehouses feature primary load-bearing components made of steel, including columns, beams, foundation, roof trusses, and roof. Wall maintenance can be accomplished with either steel or brick construction.

• Material: H-section steel beam & column
• Production Lead Time: Typically 45 days after down payment (varies by quantity)
• Quality Certification: Factory quality certificate available, with third-party inspection upon request
• Dimensions: H beam length: 4000-15000mm, Height: 200-1200mm
• Thickness: Web plate: 6-32mm, Wing plate: 6-40mm
• Color Options: Customizable to customer requirements
• Minimum Order Quantity: 1000 m² (width × length × eave height)

• Main Frame: H Steel beams and columns (Q235/Q345), painted or galvanized
• Secondary Frame: Galvanized C/Z purlins, steel bracing, tie bars, knee braces
• Roof & Wall: PU sandwich panel, Rockwool sandwich panel, or Corrugated steel sheet
• Doors & Windows: Sliding/rolling doors and aluminum alloy windows
• Surface Treatment: Two layers of rust-proof paint or Hot Dip Galvanized

• Material Testing: Thickness tolerance <0.25mm, yield and tension strength testing
• Fabrication Standards: Dimension tolerance <1mm, 20% ultrasonic and magnetic powder testing
• Surface Preparation: Shot blasting grade Sa 2.5, roughness >75μm
• Painting: Primer applied within 5 hours, DFT >75μm
• Pre-assembly testing for all connection details

All components are packed for ocean transportation in standard containers:

• 20' Container: 5.69m × 2.34m × 2.18m (24-26m³, 17.5 ton)
• 40' Container: 11.8m × 2.34m × 2.18m (54m³, 22 ton)
• HC Container: 13.58m × 2.34m × 2.71m (68m³, 29 ton)

Steel components are protected with blankets to prevent damage during transit.

Please provide the following information for accurate pricing and design:

• Project location (country/region)
• Building dimensions (length × width × height)
• Environmental factors (wind load, snow load, earthquake resistance)
• Wall requirements (brick wall height if needed)
• Insulation specifications (EPS, fiberglass wool, rockwool, or PU panels)
• Door and window quantities/sizes
• Crane specifications (if required)
