Custom Prefabricated H-Section Steel Structure Building Q235B Q355B

Custom Prefabricated H-Section Steel Structure Building Q235B Q355B
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B Custom Prefabricated H-Section Steel Structure Building Q235B Q355B Custom Prefabricated H-Section Steel Structure Building Q235B Q355B Custom Prefabricated H-Section Steel Structure Building Q235B Q355B Custom Prefabricated H-Section Steel Structure Building Q235B Q355B Custom Prefabricated H-Section Steel Structure Building Q235B Q355B Custom Prefabricated H-Section Steel Structure Building Q235B Q355B

Large Image :  Custom Prefabricated H-Section Steel Structure Building Q235B Q355B

Product Details:
Place of Origin: Qingdao,China
Brand Name: Ruly Steel
Certification: CE,AISC,SGS, BV, ISO,GB
Model Number: RULYC014
Payment & Shipping Terms:
Minimum Order Quantity: 200 square meters
Price: USD19-USD39 Per Square Meter
Packaging Details: 40HQ/Open top container
Delivery Time: 20 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 20,000 square meters or 1,500 tons per month
Contact Now

Custom Prefabricated H-Section Steel Structure Building Q235B Q355B

Description
Features: Prefab Steel Structure, Large Span, Multi-Floor Raw Steel Material: Q235B, Q355B, ASTM A36
Application: Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part Surface Treatment: Painting Or Hot-DIP Galvanized
Service Life: 50 Years Wall And Roof: Steel Cladding Sheet,Sandwich Panel
Columns & Beams: H-Section Steel Shot Blasting Level: SA 2.5
Certification: CE, AISC, SGS, BV, ISO, GB Installation: Engineer Guidance On Site
Drawing: CAD, TEKLA, 3D Model, PKPM, BIM HS Code: 9406900090
Transport Package: Standard Export Package Or Customer′s Requirement Production Capacity: 30000ton/Year
Connection Form: Bolt Connection
Highlight:

Customized Steel Structure Building

Customized Steel Structure Building Prefabricated H-Section Steel
Product Specifications
Attribute Value
Raw Steel Material Q235B, Q355B, ASTM A36
Application Steel Workshop, Steel Structure Platform, Structural Roofing, Frame Part
Surface Treatment Painting or Hot-DIP Galvanized
Service Life 50 Years
Wall and Roof Steel cladding sheet, Sandwich Panel
Columns & Beams H-Section Steel
Shot Blasting Level SA 2.5
Certification CE, AISC, SGS, BV, ISO, GB
Installation Engineer Guidance on Site
Drawing CAD, TEKLA, 3D Model, PKPM, BIM
HS Code 9406900090
Transport Package Standard Export Package or Customer's Requirement
Production Capacity 30000ton/Year
Features Prefab Steel Structure, Large Span, Multi-Floor
Connection Form Bolt Connection
Customized Steel Structure Building For Prefabricated Pet Feed Processing Factory
A steel structure pet food processing factory is specifically designed for pet food production and packaging. The steel construction ensures durability and accommodates manufacturing requirements with:
  • Robust steel framework for structural integrity and stability
  • Large windows and entrances for natural light and easy access
  • Spacious interior layout for efficient workflow and equipment installation
  • Specialized sections for raw material storage, processing, mixing, cooking, drying, and packaging
  • Stainless steel surfaces meeting stringent hygiene standards
  • Support for heavy machinery and high-temperature equipment
Main Steel Frame System
Component Specification
Main structure H section steel Q355, alkyd painting, two primary painting, two finish painting
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Ordinary bolt Galvanized bolt M20
Ordinary bolt Galvanized bolt M12
Brace nut Galvanized bolt M12
Bracing System
Component Specification
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Component Specification
Roof panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Wall panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Edge cover 0.5mm color plate, angle Alu.
Fittings & accessories Nails, glue etc.
Unpowered ventilator Diameter Φ600, stainless steel
Sky lighting band 1.2mm FRP, double layer
Sliding door sandwich panel door
Roof Drainage System
Component Specification
Gutter 0.5mm color steel plate
Rainspout pipes Φ110 PVC pipe
Company Profile
Qingdao Ruly Steel Engineering Co., Ltd is a professional steel structure design, research, fabrication and construction company located in Qingdao, China. Our 35,000 square meter facility includes a 20,000 square meter processing plant with monthly production capacity exceeding 2000 tons.
We specialize in prefabricated steel structures including warehouses, workshops, storage sheds, garages, hangars, and various commercial buildings. Our products are exported worldwide with certifications including AWS D1.1, CE, ISO 14001, ISO9001, ISO45001, AS/NZS 1554, SGS and BV.
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 0 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 1 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 2 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 3 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 4
Our Services
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 5 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 6
Our Certifications
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 7 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 8
Packing and Loading
All structural components, panels, bolts and accessories are packed for ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to prevent damage during loading.
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 9 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 10 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 11
Why Choose Us
  • Professional design team for customized solutions
  • Skilled fabrication team with advanced equipment
  • One-stop service for complete project solutions
  • Quality control team ensuring product standards
  • Comprehensive after-sales service and support
Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 12 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 13 Custom Prefabricated H-Section Steel Structure Building Q235B Q355B 14
How to Get a Quote
Please provide the following information for an accurate quotation:
Question Details Required
Location Country, area where it will be built
Size Length*width*height (mm)
Wind load Max. wind speed (kn/m², km/h, m/s)
Snow load Max. snow height (kn/m², mm)
Anti-earthquake Required level
Brickwall needed If yes, 1.2m high or 1.5m high
Thermal insulation Type: EPS, fiberglass wool, rockwool, PU sandwich panels or metal sheets
Door quantity & size Units, width*height (mm)
Window quantity & size Units, width*height (mm)
Crane needed If yes, units, max lifting weight (tons), max lifting height (m)
