Prefab Steel Structure Warehouse Large Span with Mezzanine Crane

Prefab Steel Structure Warehouse Large Span with Mezzanine Crane
Prefab Steel Structure Warehouse Large Span with Mezzanine Crane Prefab Steel Structure Warehouse Large Span with Mezzanine Crane Prefab Steel Structure Warehouse Large Span with Mezzanine Crane Prefab Steel Structure Warehouse Large Span with Mezzanine Crane Prefab Steel Structure Warehouse Large Span with Mezzanine Crane Prefab Steel Structure Warehouse Large Span with Mezzanine Crane

Large Image :  Prefab Steel Structure Warehouse Large Span with Mezzanine Crane

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: CE,AISC,SGS, BV, ISO,GB
Model Number: RulyY0012
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Warehouse Large Span with Mezzanine Crane

Description
Features: Prefab Steel Structure,Large Span,Mezzanine,Crane Application: Steel Structure Workshop
Type: Large Span Easy Assemble Steel Warehouse Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Or Hot-dip Galvanize Service Life: 50 Years
Wall And Roof: Steel Cladding Sheet,Sandwich Panel Working Scope: Design,Fabrication, Installation
Highlight:

Q235B Modern Steel Structure Warehouse

,

Mezzanine Steel Structure Warehouse

,

Galvanized Prefab Warehouse Building

Modern Prefab Steel Structure Warehouse Large Span With Mezzanine Crane
Application
Steel Structure Workshop
Type
Large Span Easy Assemble Steel Warehouse
Features
Prefab steel structure, Large Span, Mezzanine, Crane
Raw steel material
Q235B, Q355B
Surface treatment
Painting or Hot-dip Galvanize
Service life
50 Years
Wall and Roof
Steel Cladding Sheet, Sandwich Panel
Working scope
Design, Fabrication, Installation
Project Description
Our modern prefab steel structure warehouse offers the best combination of price, design stability, and functionality for large span applications with mezzanine and crane capabilities.
Key Benefits
  • Environmental Protection: Light steel construction reduces water and soil resource costs compared to traditional cement warehouses, using eco-friendly color steel materials.
  • Popular Modern Solution: Steel structures are the most popular mainstream building materials in today's construction industry.
  • Superior Protection: Excellent thermal insulation and anti-corrosion properties protect stored goods and extend the structure's lifespan.
Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 0
Product Advantages
  • Wide span capability: Available in single or multi-span configurations
  • Cost-effective: Competitive pricing from $50/m² to $80/m² based on specifications
  • Long lifespan: 20-50 years of reliable service
  • Fast construction: Easy installation with minimal on-site work
  • Additional benefits: Environmental protection, stable structure, earthquake resistance, waterproofing, and energy conservation
Technical Specifications
Component Specification
Main Frame H beam: 400-1500mm, Web plate: 6-32mm, Wing plate: 6-40mm
Height Range 200-1200mm
Color Options Customizable to customer requirements
Main Components Base (cement and steel foundation bolts), H beam frame, C/Z purlins, X-type bracing
Materials Q235B, Q355B or custom materials as requested
Surface Treatment Anti-rust painting or hot dip galvanized
Detailed Components Breakdown
Main Steel Frame System
Component Specification
Main structure H section steel Q355, alkyd painting (two primary, two finish coats)
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Bolts Grade 10.9 intensive bolts, M20+2 turn buckle bolts, M24 anchor bolts
Bracing System
Component Specification
Cross brace Φ20 round steel bar Q235, painted
Angle brace L50*5 angle steel Q235, painted
Column bracing Φ25 round steel bar Q235, painted
Tie bar Φ127*3 steel pipe Q235, painted
Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 1
Our Manufacturing Capabilities
We operate three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various types of profiling steel sheet machines with advanced equipment including plasma cutting machines.
Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 2 Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 3 Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 4 Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 5
Installation Options
  • We provide detailed shop drawings prior to installation
  • Optional training in our factory with sample assembly demonstration when needed
Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 6
Packing & Shipping
All structural components, panels, bolts and accessories are properly packed for ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to ensure safe loading at our factory.
Prefab Steel Structure Warehouse Large Span with Mezzanine Crane 7
Why Choose Our Steel Structures?
  • Expert Design: Custom drawings based on your requirements or calculations from your existing plans
  • Advanced Manufacturing: Skilled fabrication team with modern equipment and project-specific production schedules
  • Complete Solutions: One-stop service with integrated project proposals
  • Quality Assurance: Professional QC team ensures products meet your specifications
  • After-Sales Support: Comprehensive maintenance advice for insulation and steel components
Request a Quote
1. Location (where will be built?)
2. Size: length*width*height
3. Wind load (max. wind speed)
4. Snow load (max. snow height)
5. Anti-earthquake requirements
6. Brick wall needed?
7. Thermal insulation requirements
8. Door quantity & size
9. Window quantity & size
10. Crane requirements
