Prefab Steel Office Building Multi-Storey PEB Structure Q355B

Prefab Steel Office Building Multi-Storey PEB Structure Q355B
Prefab Steel Office Building Multi-Storey PEB Structure Q355B
Prefab Steel Office Building Multi-Storey PEB Structure Q355B Prefab Steel Office Building Multi-Storey PEB Structure Q355B Prefab Steel Office Building Multi-Storey PEB Structure Q355B Prefab Steel Office Building Multi-Storey PEB Structure Q355B Prefab Steel Office Building Multi-Storey PEB Structure Q355B Prefab Steel Office Building Multi-Storey PEB Structure Q355B Prefab Steel Office Building Multi-Storey PEB Structure Q355B

Large Image :  Prefab Steel Office Building Multi-Storey PEB Structure Q355B

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV
Model Number: Ruly0388
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Office Building Multi-Storey PEB Structure Q355B

Description
Features: Multi-Storey Steel Structure Building Application: Prefab Steel Building
Type: PEB Steel Buildings Raw Steel Material: Q235B, Q355B
Surface Treatment: Painting Or Hot-dip Galvanize Service Life: 50 Years
Wall And Roof: Glass Wool Working Scope: Design,Fabrication, Installation
Highlight:

Prefab Q235B Steel Structure Office Building

,

Q355B Multi Storey Steel Structure Building

,

Office PEB Steel Buildings

Prefabricated Office Steel Structure Building Multi Storey
Product Specifications
Attribute Value
Application Prefab Steel Building
Features Multi-Storey Steel Structure Building
Type PEB Steel Buildings
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Glass wool
Working scope Design, Fabrication, Installation
Project Overview

Prefabricated Steel Structure Office Buildings offer numerous advantages over traditional concrete construction, including attractive appearance, vibrant colors, diverse architectural shapes, cost-effectiveness, shorter construction timelines, and high factory production efficiency of steel components.

Structural Components & Technical Parameters
Main Steel Frame System
  • Main structure: H section steel Q355, alkyd painting (two primary coats, two finish coats)
  • Roof purlin: XZ160*60*20*2.5, galvanized
  • Wall purlin: XZ160*60*20*2.5, galvanized
  • Intensive bolt: Grade 10.9
  • Anchor bolt: M24, steel Q235
Bracing System
  • Cross brace: Φ20 round steel bar Q235, painted
  • Angle brace: L50*5 angle steel Q235, painted
  • Column bracing: Φ25 round steel bar Q235, painted
Wall & Roof System
  • Roof panel: Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
  • Wall panel: Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
  • Unpowered ventilator: Diameter Φ600, stainless steel
Prefab Steel Office Building Multi-Storey PEB Structure Q355B 0
Our Manufacturing Facility
Prefab Steel Office Building Multi-Storey PEB Structure Q355B 1
Installation Options
  • We provide detailed shop drawings prior to installation
  • On-site training available at our factory, including sample assembly when required
Prefab Steel Office Building Multi-Storey PEB Structure Q355B 2
Packaging & Shipping

All components are packed for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to ensure damage-free loading at our factory.

Prefab Steel Office Building Multi-Storey PEB Structure Q355B 3
Our Advantages
  • Professional design team for customized solutions
  • Skilled fabrication with advanced equipment
  • Complete project management from design to installation
  • Quality control at every production stage
  • Comprehensive after-sales support
Quotation Requirements
Question Details Required
Location Country and area where building will be constructed
Dimensions Length × Width × Height (mm)
Environmental Loads Wind speed (kn/m², km/h, m/s) and snow height (kn/m², mm)
Seismic Requirements Earthquake resistance level
Insulation Type (EPS, fiberglass, rockwool, PU) or metal sheets
