Large Span Steel Warehouse Building with Sandwich Panel Walls

Large Span Steel Warehouse Building with Sandwich Panel Walls
Large Span Steel Warehouse Building with Sandwich Panel Walls
Large Span Steel Warehouse Building with Sandwich Panel Walls Large Span Steel Warehouse Building with Sandwich Panel Walls Large Span Steel Warehouse Building with Sandwich Panel Walls Large Span Steel Warehouse Building with Sandwich Panel Walls Large Span Steel Warehouse Building with Sandwich Panel Walls Large Span Steel Warehouse Building with Sandwich Panel Walls Large Span Steel Warehouse Building with Sandwich Panel Walls

Large Image :  Large Span Steel Warehouse Building with Sandwich Panel Walls

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0385
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Large Span Steel Warehouse Building with Sandwich Panel Walls

Description
Features: Large Span Steel Structure Construction Application: Logistics Steel Warehouse Buildings Contractor
Type: Portal Frame Steel Warehouse Working Scope: Design,Fabrication, Installation
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting
Service Life: 50 Years Wall And Roof: Sandwich Panel
Highlight:

Large Span Q235B Steel Structure Construction

,

BV Logistics Warehouse Steel Structure Construction

,

Z Purlin Logistics Steel Structure Building

Large Span Steel Structure Construction for Logistics Steel Warehouse Buildings
Product Specifications
Attribute Value
Application Logistics Steel Warehouse Buildings Contractor
Features Large Span Steel Structure Construction
Type Portal frame steel warehouse
Working scope Design, Fabrication, Installation
Raw steel material Q235B, Q355B
Surface treatment Painting
Service life 50 Years
Wall and Roof Sandwich panel
Key Advantages
  • High-opening interior space: Minimum 9 meters net height, 12m x 28m column spacing for flexible warehouse layout
  • Efficient unloading facilities: 1.3m high, 4.5m wide unloading area with electric lift doors and 6.5m wide canopy
  • Optimized work environment: Natural lighting belts, roof ventilators, and corundum wear-resistant flooring
Technical Specifications
Component Specification
Main Steel Frame (Column/Beam) Q235, Q345 Welded H Section Steel
Secondary Frame Q235 C and Z purlin, Angle Steel, Circular Steel Pipe, Round Bar
Maintenance System Various sandwich panel options for roof and walls
Accessories Aluminum/PVC windows, various door types, PVC rainspout
Structural Performance 120kg/sqm roof load, Grade 12 wind resistance, Grade 8 earthquake resistance
Environmental Tolerance -50°C to +50°C operating range
Certifications CE, SGS, ISO9001:2008, ISO14001:2004
Finishing Options Wide color selection with alkyd or galvanized paint systems
Production Capabilities
Large Span Steel Warehouse Building with Sandwich Panel Walls 0
Installation Process

We provide detailed construction drawings for each project and can dispatch engineers for on-site guidance or complete the installation with our construction team.

Large Span Steel Warehouse Building with Sandwich Panel Walls 1
Packaging & Shipping

All components are packed for ocean transportation in 40'HQ containers, with careful loading by skilled workers using cranes and forklifts to prevent damage.

Large Span Steel Warehouse Building with Sandwich Panel Walls 2
Quotation Requirements
Item Details Required
1 Location (country, area)
2 Dimensions (length × width × height in mm)
3 Wind load (max wind speed in kn/m², km/h, or m/s)
4 Snow load (max snow height in kn/m² or mm)
5 Earthquake resistance level
6 Brick wall requirements (height if needed)
7 Thermal insulation specifications
8 Door quantity and dimensions
9 Window quantity and dimensions
10 Crane requirements (quantity, capacity, height)
