Product Details:
|
Application: | Steel Structure Warehouse | Usage: | Steel Structure Logistics Warehouse,Steel Structure Workshop, Metal Warehouse, Factory Buildings |
---|---|---|---|
Type: | Pre Engineered Steel Structure | Raw Steel Material: | Q235B, Q355B, ASTM A36 |
Service Life: | 50 Years | Working Scope: | Design,Fabrication, Installation |
Columns & Beams: | H-section Steel | Surface Treatment: | Painting Or Hot-dip Galvanize |
Highlight: | Q355B Steel Structure Logistics Warehouse,Prefabricated Steel Structure Logistics Warehouse,Q235B Prefabricated Steel Structure Building |
Attribute | Value |
---|---|
Application | Steel Structure Warehouse |
Usage | Steel Structure Logistics Warehouse, Steel Structure Workshop, Metal Warehouse, Factory Buildings |
Type | Pre Engineered Steel Structure |
Raw steel material | Q235B, Q355B, ASTM A36 |
Service life | 50 Years |
Working scope | Design, Fabrication, Installation |
Columns & Beams | H-section steel |
Surface treatment | Painting or Hot-dip Galvanize |
Item | Specification |
---|---|
Main Pillar & Beams | Q355B |
Roof Purlins | C200*70*20*2.5 Galvanize |
Tie Bar | Φ114*4 |
Pillar Supporters | Φ20 |
Tie rod | Φ12,Φ32*2.5 |
Kneebracing | L50*4 |
Foundation bolt | M24 |
General Bolts | C Grade |
Bolt screw | Φ19 |
High Strengthened Bolts | 10.9 Grade |
Roof Panel | 0.5mm Galvanized Steel Plate |
Ribbon skylight | 1.2mm FRP |
Floor Steel deck | 1.00 mm steel plate |
Doors | Sliding door |
Windows | Steel windows |
Gutters | 3mm thick galvanized steel |
Edge and corner wrapping | 0.5mm Galvanized Steel Plate |
Down pipe | Φ140PVC |
