Large Span Prefabricated Steel Frame Buildings for Warehouses

Large Span Prefabricated Steel Frame Buildings for Warehouses
Large Span Prefabricated Steel Frame Buildings for Warehouses
Large Span Prefabricated Steel Frame Buildings for Warehouses Large Span Prefabricated Steel Frame Buildings for Warehouses Large Span Prefabricated Steel Frame Buildings for Warehouses Large Span Prefabricated Steel Frame Buildings for Warehouses Large Span Prefabricated Steel Frame Buildings for Warehouses Large Span Prefabricated Steel Frame Buildings for Warehouses Large Span Prefabricated Steel Frame Buildings for Warehouses

Large Image :  Large Span Prefabricated Steel Frame Buildings for Warehouses

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, ,ISO, BV
Model Number: Ruly0283
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Large Span Prefabricated Steel Frame Buildings for Warehouses

Description
Application: Large Span Prefabricated Steel Frame Buildings ,Steel Space Frame Structures Usage: Logistics Warehouse Buildings, Metal Warehouse, Factory Buildings
Type: Prefabricated Steel Frame Buildings Raw Steel Material: Q235B, Q345B
Surface Treatment: Painting Or Hot-dip Galvanize Service Life: 50 Years
Wall And Roof: EPS Sandwich Panel Columns And Beam: H Section Column&Beam
Highlight:

Large Span Prefabricated Steel Frame Buildings

,

Q345B Prefabricated Steel Frame Buildings

,

Large Span Steel Space Frame Structures

Large Span Prefabricated Steel Frame Buildings Steel Space Frame Structures
Product Attributes
Attribute Value
Application Large Span Prefabricated Steel Frame Buildings, Steel Space Frame Structures
Usage Logistics Warehouse Buildings, Metal Warehouse, Factory Buildings
Type Prefabricated Steel Frame Buildings
Raw Steel Material Q235B, Q345B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof EPS sandwich panel
Columns and Beam H Section Column & Beam
Project Description
The building is designed for goods storage, featuring multi-edge, multi-span steel frame structure with a total construction area of approximately 36,000 square meters.
Utilizing light high-strength steel beam-column connection main steel frame structure for space efficiency, cost savings, and reduced weight. Rock wool sandwich board is used for roof and wall insulation.
We provide comprehensive one-stop service including design, BIM process, detailed drawings, steel structure fabrication, shipping, and installation.
Large Span Prefabricated Steel Frame Buildings for Warehouses 0
Steel Structure Specifications
Item name Specification Material Parameter Technical Treatment
Column H shape, Box, steel pipe, Hot rolled sheet Q235B, Q355B Paint or Hot dip galvanized
Beam H shape, steel Truss, Hot rolled sheet Q235B, Q355B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B, Q355B
Purling C or Z shape, purling Thickness:1.8mm~3.0mm Q235B, Q355B Hot dip galvanized
Wall and roof panel Rock wool Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet, T=1.0~1.5mm Paint or Hot dip galvanized
Window alloy-Glass, Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion:2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel, stainless steel, PC Paint or Hot dip galvanized, 304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized, 304
Downpipe PVC pipe, Color steel pipe T=0.5mm Φ110, 160, 200 Paint
Bolt Ordinary, high strength 10.9S, 4.8s Hot dip galvanized
Anchor bolt Steel rod M24, M27 M30 Q235B
Design
Large Span Prefabricated Steel Frame Buildings for Warehouses 1
Annual Maintenance Guidelines
  • After installation, structural modifications should only be made after consulting with the manufacturer. The steel structure requires repainting approximately every 3 years to maintain both aesthetics and safety.
  • Regular cleaning and maintenance should be performed annually. When cleaning exterior walls, avoid abrasive materials and use clean water from top to bottom.
  • Promptly remove debris like branches and leaves to prevent accumulation. Repair any surface damage to metal plates immediately to prevent corrosion.
  • Consider applying high-elastic nano materials to metal roofing panels for enhanced heat insulation, waterproofing, and energy efficiency.
