Multi-Story Modular Steel Hotels with Curtain Glass Wall Design
The Multi-Story Modular Steel Hotels with Curtain Glass Wall Design is an innovative construction solution for hotels, resorts, serviced apartments, and hospitality developments. Manufactured with high-strength structural steel and precision-engineered components, it combines architectural flexibility, rapid construction, and long-term durability to meet the demands of modern accommodation projects.
Compared with conventional concrete buildings, steel structure hotels offer significantly shorter construction periods, reduced structural weight, and improved construction efficiency. Factory-prefabricated components ensure high dimensional accuracy and consistent quality, minimizing on-site work while accelerating project completion.
The building can be customized for single-storey or multi-storey configurations, accommodating guest rooms, suites, reception areas, restaurants, conference rooms, recreational facilities, and other public spaces.
To ensure long service life in different environments, the steel structure can be finished with alkyd paint, epoxy coating, or hot-dip galvanizing. Combined with high-performance insulation systems, the building provides excellent energy efficiency, indoor comfort, and reduced maintenance costs throughout its service life.
From structural engineering and shop drawings to fabrication, quality inspection, packaging, shipping, and installation support, our experienced team provides comprehensive project services tailored to each client's requirements. Whether for luxury resorts, business hotels, boutique accommodations, or tourism developments, our prefabricated steel structure hotel buildings deliver a reliable, efficient, and cost-effective solution for modern hospitality construction.
| Name |
Multi-Story Modular Steel Hotels with Curtain Glass Wall Design |
| Structure Type |
portal frame structure, truss frame, flat frame structure |
| Length |
20m~200m |
| Width |
20m~50m |
| Height |
4m~30m |
| Roof Slope |
Recommend 5~15% according to site |
| Steel beam & Column |
H-section steel, truss steel, steel tube, latticed steel, cross-section steel |
| Roof & Wall cladding |
Galvanized steel cladding sheet, sandwich panel (view different panel cores below)
|
| Door |
Sliding door, folding door, roller shutter door, etc. |
| Window |
Aluminum alloy frame window, louvers, etc. |
| Anti-corrosion for steel structure |
Alkyd painting, Epoxy painting or Hot-dip galvanized |
Our Service
| Service |
Description |
| Steel Structure Fabrication |
Cutting, welding, painting, hot-dip galvanizing, and pre-assembly of structural steel components. |
| Design & Engineering |
Design, engineering, fabrication, and installation support for prefabricated steel buildings. |
| Shop Drawing Services |
Detailed fabrication drawings and shop drawings based on client-provided architectural and structural plans. |
| Engineering Consulting |
Structural optimization, technical consultation, and project support from design to construction. |
Comparison of Roofing and Wall Systems
| Item |
Steel Sheet |
EPS Panel |
Rock Wool Panel |
PU/PIR Panel |
Glass Fiber + PVC/Aluminum Foil |
| Initial Cost |
Lowest |
Low-Medium |
Medium |
High |
Low |
| Thermal Performance |
Poor |
Good |
Good |
Excellent |
Good |
| Fire Resistance |
Poor |
Moderate |
Excellent |
Good |
Moderate |
| Sound Absorption |
Poor |
Moderate |
Good |
Good |
Moderate |
| Recommended Application |
Warehouses, sheds, equipment shelters in mild climates |
Industrial buildings requiring economical insulation |
Factories, warehouses, workshops with high fire protection requirements |
Cold storage, food processing plants, energy-efficient industrial buildings |
Large-span steel buildings requiring economical thermal insulation |
Quality Inspection
| Inspection Item |
Purpose |
Details |
| Material Inspection |
Verify raw material quality |
·Thickness tolerance <0.25mm
·Yield and tension strength testing in-house
·Third party inspection certificate
·Traceable mill certificate
|
| Welding Inspection |
Ensure weld integrity |
·100% testing dimension tolerance <1mm
·20% sample welding line ultrasonic testing, no fault, full penetration
·20% magnetic particle testing, no bubble, no defect
·Third-party inspection available
|
| Coating Inspection |
Check paint thickness |
·Surface Preparation Grade Sa 2.5, no visible rust, no mill scale and contaminants, welding spatters removed
·Primer to be applied within 4-6 hours after blasting and before any visible flash rusting occurs. Dry film thickness (DFT) : 75 ± 15 μm
|
Magnetic Particle Testing
Packaging&Shipping
All steel components are bundled and secured on steel pallets for safe handling and transportation.
The pallets are loaded into containers using gantry cranes and forklifts, ensuring efficient and damage-free loading.
