Q235B Q355B Steel Structure Construction with Painting Surface

Q235B Q355B Steel Structure Construction with Painting Surface
Q235B Q355B Steel Structure Construction with Painting Surface
Q235B Q355B Steel Structure Construction with Painting Surface Q235B Q355B Steel Structure Construction with Painting Surface Q235B Q355B Steel Structure Construction with Painting Surface Q235B Q355B Steel Structure Construction with Painting Surface Q235B Q355B Steel Structure Construction with Painting Surface Q235B Q355B Steel Structure Construction with Painting Surface Q235B Q355B Steel Structure Construction with Painting Surface

Large Image :  Q235B Q355B Steel Structure Construction with Painting Surface

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0225
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Q235B Q355B Steel Structure Construction with Painting Surface

Description
Features: Structural Steel Frame Construction Application: Metal Frame Construction, Industrial Steel Structures
Raw Steel Material: Q235B, Q355B Type: Steel Structure Construction
Working Scope: Design,Fabrication, Installation Surface Treatment: Painting
Service Life: 50 Years Wall And Roof: Steel Cladding Sheet
Highlight:

steel frame building

,

prefab metal buildings

Q235B Q355B Steel Structure Construction / Metal Frame Construction Painting Surface
Product Specifications
Attribute Value
Application Metal Frame Construction, Industrial Steel Structures
Features Structural Steel Frame Construction
Raw steel material Q235B, Q355B
Type Steel Structure Construction
Working scope Design, Fabrication, Installation
Surface treatment Painting
Service life 50 Years
Wall and Roof Steel cladding sheet
Product Description
Our metal frame construction solutions include prefabricated steel structures for various applications such as warehouses, workshops, storage sheds, garages, hangars, and commercial buildings. We handle complete projects from design to installation.
Key Cost Factors
  • Building height: Construction cost increases by 2-3% for every 10cm increase
  • Crane requirements: Proper tonnage selection is crucial for cost efficiency
  • Protection structures: Doors, windows, and exterior walls affect overall cost
  • Design structure: Building purpose, location, and usage requirements
  • Construction area: Larger areas require more steel, increasing costs
  • Span length: Generally, larger spans result in lower costs per unit
  • Steel quantity: The most significant cost factor, affected by design and material source
Material Specifications
Item name Specification Material Parameter Technical Treatment
Column H-section steel Q235B,Q345B Paint or Hot dip galvanized
Beam H-section steel Q235B,Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B,Q345B
Purling C or Z shape, purling Thickness:1.8mm~3.0mm Q235B,Q346B Hot dip galvanized
Wall and roof panel EPS,Rock wool,Pu,Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Door Sliding or rolling door Steel or Aluminum sheet,T=1.0~1.5mm Paint or Hot dip galvanized
Window alloy-Glass, Aluminium alloy-shutter T=1.0~2.0mm Alloy
Lighting panel FRP, T=1.5mm or T=1.8mm Coefficient of thermal expansion:2.2x10-5/cm/cm/℃ Light transmittance 85%
Ventilator Turbine ventilator, and electric type Steel, stainless steel, PC Paint or Hot dip galvanized,304
Gutter Galvanized or stainless steel plate T=2.0mm Hot dip galvanized,304
Downpipe PVC pipe, Color steel pipe T=0.5mm Φ110,160,200 Paint
Bolt Ordinary, high strength 10.9S,4.8s Hot dip galvanized
Anchor bolt Steel rod M24,M27 M30 Q235B
Q235B Q355B Steel Structure Construction with Painting Surface 0
Design Capabilities
Our dedicated engineering department maintains a complete steel structure design system, optimizing for reliability, economy, and architectural aesthetics. We carefully consider material selection and combinations to deliver structures that are not only safe and cost-effective but also visually appealing.
Q235B Q355B Steel Structure Construction with Painting Surface 1
Installation Services
We provide detailed installation drawings for each project and can dispatch engineers to guide the installation process or handle the complete installation ourselves.
Q235B Q355B Steel Structure Construction with Painting Surface 2
Quotation Information
Please provide the following details for an accurate quote:
Item Details Required
Location Country, area where the structure will be built
Size Length × width × height (mm)
Wind load Maximum wind speed (kn/m², km/h, or m/s)
Snow load Maximum snow height (kn/m² or mm)
Earthquake resistance Required seismic level
Brickwall requirements If needed, specify height (1.2m or 1.5m)
Thermal insulation Specify material if required (EPS, fiberglass wool, rockwool, PU)
Door specifications Quantity and dimensions (width × height in mm)
Window specifications Quantity and dimensions (width × height in mm)
Crane requirements If needed, specify quantity, max lifting weight (tons), and height (m)
