Prefab Steel Workshop with Glass Wool Sandwich Panels

Prefab Steel Workshop with Glass Wool Sandwich Panels
Prefab Steel Workshop with Glass Wool Sandwich Panels
Prefab Steel Workshop with Glass Wool Sandwich Panels Prefab Steel Workshop with Glass Wool Sandwich Panels Prefab Steel Workshop with Glass Wool Sandwich Panels Prefab Steel Workshop with Glass Wool Sandwich Panels Prefab Steel Workshop with Glass Wool Sandwich Panels Prefab Steel Workshop with Glass Wool Sandwich Panels Prefab Steel Workshop with Glass Wool Sandwich Panels

Large Image :  Prefab Steel Workshop with Glass Wool Sandwich Panels

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0155
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Workshop with Glass Wool Sandwich Panels

Description
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting
Shot Blasting Level: Sa 2.5 Service Life: 50 Years
Wall And Roof: Glass Wool Sandwich Panel Type: Steel Frame Structure Workshop
Working Scope: Design,Fabrication, Installation Application: Car Maintenance Shop, Auto Repair Shops
Highlight:

steel frame building

,

steel frame construction

Workshop Prefabricated Steel Buildings With Glass Wool Sandwich Panel Wall
Product Overview

Prefabricated steel buildings with glass wool sandwich panel walls designed specifically for car maintenance and auto repair shops. The steel frame structure features welded H-section steel columns and beams connected by high-strength bolts.

Key Specifications
Attribute Specification
Raw steel material Q235B, Q355B
Surface treatment Painting
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Glass wool sandwich panel
Type Steel frame structure workshop
Working scope Design, Fabrication, Installation
Application Car Maintenance Shop, Auto Repair Shops
Structural Details
Parameter Specification
Structure Type Gable frame, single ridge, clean span or two spans
Length 40-100m
Width 20-80m
Eave Height 6-15m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Door Type Sliding door
Window Type Ribbon Skylight
Material Specifications
Component Material Treatment
Column H-section steel (Q235B,Q345B) Paint or Hot dip galvanized
Beam H-section steel (Q235B,Q345B) Paint or Hot dip galvanized
Purlin C or Z shape (Thickness:1.8mm~3.0mm) Hot dip galvanized
Wall/Roof Panel Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Our Manufacturing Capabilities

We operate three production lines with advanced equipment including plasma cutting machines for precise steel structure fabrication.

Prefab Steel Workshop with Glass Wool Sandwich Panels 0
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Complete design, fabrication and installation of prefabricated steel buildings
  • Custom fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Prefab Steel Workshop with Glass Wool Sandwich Panels 1
Installation Support

We provide detailed installation drawings and can dispatch engineers to guide the installation process or handle complete installation.

Prefab Steel Workshop with Glass Wool Sandwich Panels 2
Packaging & Shipping

All components are packed securely for ocean transportation in 40'HQ containers, with careful loading by experienced workers to prevent damage.

Prefab Steel Workshop with Glass Wool Sandwich Panels 3
