Truss Roof Steel Structure Warehouse for Factory Construction

Large Image : Truss Roof Steel Structure Warehouse for Factory Construction

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, ,ISO,BV
Model Number:	Ruly0041

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Truss Roof Steel Structure Warehouse for Factory Construction

Description

Features:	Truss Steel Buildings	Application:	Truss Roof Steel Structure Warehouse
Type:	Factory Buildings Construction	Raw Steel Material:	Q235B, Q355B
Surface Treatment:	Painting Or Hot-dip Galvanize	Wall And Roof:	Steel Cladding/Rock Wool/Glass Wool/EPS/PU Sandwich Panel
Columns And Beam:	H Section Column&Beam	Installation:	Engineer Guidance On Site
Highlight:	steel frame building , prefab metal buildings

Truss Roof Steel Structure Warehouse For Factory Buildings Construction

Product Attributes

Attribute	Value
Application	Truss Roof Steel Structure Warehouse
Features	Truss Steel Buildings
Type	Factory Buildings Construction
Raw steel material	Q235B, Q355B
Surface treatment	Painting or Hot-dip Galvanize
Wall and Roof	Steel cladding/Rock wool/Glass wool/EPS/PU sandwich panel
Columns and Beam	H Section Column & Beam
Installation	Engineer guidance on site

Product Description

Steel truss is a structure consisting of rods connected by hinges at each end. Compared with H-Section steel beam as roof, when the span is large, it can save materials, reduce dead weight and increase stiffness compared to solid-web beams, which require larger sections and thickness to match strength requirements for large spans.

Every steel roof truss is custom-designed based on the unique load, span, bearing, use, and code criteria of each project. This project includes both solid-web beams and steel trusses, all fabricated in our steel structure factory before installation.

Technical Specifications

Item	Details
Material	Carbon structural steel
Production Lead Time	Normally 45 days after down payment (varies by quantity)
Quality Certification	Factory quality certificate, third-party available upon request
Dimensions	H beam: 4000-15000mm
Thickness	Web plate: 6-32mm, Wing plate: 6-40mm
Height	200-1200mm
Color	Customizable
Minimum Order Quantity	1000 m² (width × length × eave height)

Main Components

Base: Cement and steel foundation bolts
Main Frame: H Steel beam (Q235/Q345), painted or galvanized columns
Secondary Frame: Galvanized C/Z purlins, steel bracing, tie bars, knee braces
Roof & Wall: PU sandwich panel, Rockwool panel, or corrugated steel sheet
Surface Treatment: Two layers of rust-proof paint or hot-dip galvanized
Accessories: Skylight belts, ventilators, down pipes, gutters, flashing

Our Steel Structure Fabrication Factory

Our 35,000㎡ facility includes 20,000㎡ of workshop space with three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines, and advanced equipment including plasma cutting machines.

Packing and Loading

All structural components, panels, bolts, and accessories are packed securely for ocean transportation and loaded into 40'HQ containers.

Why Choose Us

Professional design team for custom drawings and calculations
Skilled fabrication team with advanced equipment
One-stop service with integrated project proposals
Quality control team ensuring product specifications
Comprehensive after-sales service and maintenance support
