Prefabricated Steel Frame Building for Farmers Produce Market

Prefabricated Steel Frame Building for Farmers Produce Market
Prefabricated Steel Frame Building for Farmers Produce Market Prefabricated Steel Frame Building for Farmers Produce Market Prefabricated Steel Frame Building for Farmers Produce Market Prefabricated Steel Frame Building for Farmers Produce Market Prefabricated Steel Frame Building for Farmers Produce Market Prefabricated Steel Frame Building for Farmers Produce Market

Large Image :  Prefabricated Steel Frame Building for Farmers Produce Market

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, ,ISO, BV
Model Number: Ruly0035
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Frame Building for Farmers Produce Market

Description
Application: Large Steel Frame Structure Metal Buildings Usage: Farmers Produce Market Buildings, Steel Agricultural Buildings
Type: Prefabricated Steel Frame Buildings Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Steel Cladding/Rock Wool/Glass Wool/EPS/PU Sandwich Panel
Columns And Beam: H Section Column&Beam Drawing: Design The Drawing As Your Demand
Highlight:

prefab steel structures

,

steel structure building construction

Large Steel Frame Structure Metal Buildings For Farmers Produce Market
Product Specifications
Attribute Value
Application Large Steel Frame Structure Metal Buildings
Usage Farmers Produce Market Buildings, Steel Agricultural Buildings
Type Prefabricated Steel Frame Buildings
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Steel cladding/Rock wool/Glass wool/EPS/PU sandwich panel
Columns and Beam H Section Column & Beam
Drawing Design The Drawing as Your Demand
Project Overview
Our large span steel frame structure buildings are specifically designed for farmers produce markets and vegetable markets. The column-free design maximizes interior space and convenience for movement. We ensure structural integrity through factory pre-assembly of components before installation.
As EPC contractors, we handle the complete project lifecycle including design, fabrication, and installation - typically completed within one month. These pre-engineered steel buildings are ideal for large-scale workshops, warehouses, supermarkets, and entertainment centers, offering benefits such as:
  • Easy installation process
  • Stable and durable structure
  • Earthquake resistance
  • Waterproof construction
  • Energy efficient design
  • Environmentally friendly materials
Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Horizontal brace: Φ20, Steel Q235, processed and painted
Column brace: Φ20, Steel Q235, processed and painted
Tie rod: Φ89*3, Steel Q235, processed and painted
Ordinary bolt M12 Galvanized bolt
Roof System Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Sky light: 6mm thick PVC
Wall System Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Accessories Glass cement, self-tapping screws, edge covers, gutters, down pipes
Production Capabilities
Our 35,000㎡ fabrication facility includes 20,000㎡ of workshop space equipped with:
  • Three light/heavy H steel production lines
  • BOX production lines
  • C/Z purlin production lines
  • Advanced profiling steel sheet machines
  • Plasma cutting equipment
Prefabricated Steel Frame Building for Farmers Produce Market 0
Why Choose Our Steel Structures?
  • Professional Design: Custom drawings and steel quantity calculations
  • Skilled Fabrication: Advanced equipment and project-specific production schedules
  • Complete Service: Integrated project solutions from design to installation
  • Quality Assurance: Dedicated QC team ensuring product specifications
  • After-Sales Support: Maintenance services for insulation and components
Project Questionnaire
Please provide the following information for accurate pricing and design:
Item Details Required
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. snow height) _____kn/m2, _____mm
5 Anti-earthquake _____level
6 Brickwall needed or not If yes, 1.2m high or 1.5m high
7 Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, the metal steel sheets will be ok
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
