Large Span Prefabricated Steel Building with Indoor Office

Large Span Prefabricated Steel Building with Indoor Office
Large Span Prefabricated Steel Building with Indoor Office
Large Span Prefabricated Steel Building with Indoor Office Large Span Prefabricated Steel Building with Indoor Office Large Span Prefabricated Steel Building with Indoor Office Large Span Prefabricated Steel Building with Indoor Office Large Span Prefabricated Steel Building with Indoor Office Large Span Prefabricated Steel Building with Indoor Office Large Span Prefabricated Steel Building with Indoor Office

Large Image :  Large Span Prefabricated Steel Building with Indoor Office

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, ,ISO, BV
Model Number: Ruly0024
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Large Span Prefabricated Steel Building with Indoor Office

Description
Application: Large Span Prefabricated Engineered Building Usage: PEB Steel Buildings, Metal Warehouse, Factory Buildings
Raw Steel Material: Q235B, Q355B Surface Treatment: Painting Or Hot-dip Galvanize
Service Life: 50 Years Wall And Roof: Steel Cladding/Rock Wool/Glass Wool/EPS/PU Sandwich Panel
Columns And Beam: H Section Column&Beam Service Scope: Design,Manufacture,Install
Highlight:

pre engineered steel buildings

,

pre engineered building structure

Large Span Prefabricated Engineered Building Construction With Indoor Office
Product Specifications
Application Large Span Prefabricated Engineered Building
Usage PEB Steel Buildings, Metal Warehouse, Factory Buildings
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Steel cladding/Rock wool/Glass wool/EPS/PU sandwich panel
Columns and Beam H Section Column & Beam
Service scope Design, Manufacture, Install
Project Description

This prefabricated steel structure warehouse is designed for textile storage and includes a double-floor steel office within the warehouse. We provide comprehensive fabrication services including steel beams & columns, roof & wall sandwich panels, purlins, canopies, and all necessary accessories.

Our one-stop service covers the entire process from design and BIM processes to fabrication, transportation, and installation. Simply communicate your requirements, and we'll help bring your vision to life at the most reasonable cost.

Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel plate thickness: 8-30mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Horizontal brace: Φ20, Steel Q235, processed and painted
Column brace: Φ20, Steel Q235, processed and painted
Tie rod: Φ89*3, Steel Q235, processed and painted
Ordinary bolt: M12 Galvanized bolt
Roof Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Sky light: 6mm thick PVC
Accessories: Glass cement, self-tapping screws, etc.
Edge cover: 0.4mm steel sheet profile trimming
Gutter: 0.4mm thick sheet steel profile or galvanized sheet
Down pie: Φ110PVC
Walls Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Accessories: Glass cement, self-tapping screws, etc.
Edge cover: 0.4mm steel sheet profile trimming
Ventilation: Ventilation ball
Doors & windows: Rolling door/sliding door PVC/alu/steel/window
Design Process

We provide comprehensive design services including preliminary layout plans, shop drawings, 3D Tekla Models, and construction drawings for each project.

Large Span Prefabricated Steel Building with Indoor Office 0
Installation Process

We provide detailed construction drawings prior to installation and can dispatch our engineers to guide the installation process or complete the installation with our professional construction team.

Large Span Prefabricated Steel Building with Indoor Office 1
Quality Control
  • 100% testing dimension tolerance <1mm
  • 20% sample welding line ultrasonic testing, no fault, full penetration
  • 20% magnetic powder testing, no bubble, no defect, Smooth and Full
  • Supply third-party inspection assistance
Large Span Prefabricated Steel Building with Indoor Office 2
Packing and Shipping

All structural components, panels, bolts, and accessories are packed to withstand ocean transportation and loaded into 40'HQ containers.

Large Span Prefabricated Steel Building with Indoor Office 3
