50 Year Steel Poultry House For Broiler Layer Farms With Insulated Panels Livestock Housing Solution

Large Image : 50 Year Steel Poultry House For Broiler Layer Farms With Insulated Panels Livestock Housing Solution

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	CE,AISC,SGS, BV, ISO,GB
Model Number:	RULYZ0001

Payment & Shipping Terms:

Minimum Order Quantity:	200 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

50 Year Steel Poultry House For Broiler Layer Farms With Insulated Panels Livestock Housing Solution

Description

Type:	Steel Structure Poultry House	Application:	Poultry House, Broiler Farm, Layer Farm
Working Scope:	Design,Fabrication, Installation	Raw Steel Material:	Q235B, Q355B Or Equivalent
Surface Treatment:	Painting Or Hot-dip Galvanize	Service Life:	50 Years
Highlight:	Broiler Farms Poultry House , Livestock Housing Poultry House , 50 Year Poultry House

Poultry House for Broiler, Layer & Breeder Farms – Prefabricated Steel Structure with Insulated Panels and Ventilation System

Maximize productivity and ensure optimal bird health with our high-performance poultry house, engineered for modern commercial farms. Designed for broilers, layers, and breeder flocks, this prefabricated poultry house delivers a controlled, durable, and cost-effective environment that supports higher growth rates, better feed conversion, and improved egg production.

Galvanized steel frame structure offers superior strength, corrosion resistance, and long-term durability in high-humidity and high-ammonia environments
Insulated sandwich panels (EPS, PU, PIR or Rockwool core) provide excellent thermal insulation for stable temperatures year-round
Mechanical ventilation system (customizable) includes axial fans, cooling pads, and automated side curtains or inlet baffles
Open-span design with no interior columns maximizes usable space for equipment
Factory-precut components enable fast on-site assembly with bolted connections (40-60% faster than traditional construction)

Main Parts of the Steel Structures and Technical Parameters

Main Structure

Component	Specification
Main structure	H section steel Q355, alkyd painting, two primary painting, two finish painting. Or hot-dip galvanized
Roof purlin	XZ1606020*2.5, galvanized
Wall purlin	XZ1606020*2.5, galvanized
Intensive bolt	Grade 10.9
Turn buckle bolt	M20+2, steel Q235, processing
Anchor bolt	M24, steel Q235, processing

Bracing System

Component	Specification
Cross brace	Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace	L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing	Φ25 round steel bar Q235, process and painted (alkyd painting)

Wall & Roof System

Component	Specification
Roof panel	Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU/PIR)
Wall panel	Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU/PIR)
Poultry equipment	Cooling pad, exhaust fan, etc.

Installation Options

Method 1: We provide shop drawings before installation
Method 2: We teach installation in our factory and can assemble a sample structure if needed

Packing and Transport

All structures come with full engineering drawings, load calculations, and material certifications for international compliance.

This poultry house is a smart, long-term investment in sustainable and efficient poultry farming, combining durability, climate control, and rapid deployment to support your farm's success today and into the future.
