Product Details:
|
Application: | Multi-Storey Steel Structure Warehouse | Type: | Prefabricated Steel Structure Building |
---|---|---|---|
Raw Steel Material: | Q235B, Q355B, ASTM A36 | Shot Blasting Level: | Sa 2.5 |
Service Life: | 50 Years | Wall And Roof: | Rock Wool |
Surface Treatment: | Painting | Working Scope: | Design,Fabrication, Installation |
Columns & Beams: | H-section Steel | Standard: | AISC, ASTM, BS, DIN, GB, JIS |
Highlight: | SGS Multi Storey Steel Structure Warehouse,Sa 2.5 Prefabricated Steel Structure Warehouse,Multi Storey Prefabricated Steel Structure Building |
Attribute | Value |
---|---|
Application | Multi-Storey Steel Structure Warehouse |
Type | Prefabricated Steel Structure Building |
Raw steel material | Q235B, Q355B, ASTM A36 |
Shot blasting level | Sa 2.5 |
Service life | 50 Years |
Wall and Roof | Rock wool |
Surface treatment | Painting |
Working scope | Design, Fabrication, Installation |
Columns & Beams | H-section steel |
Standard | AISC, ASTM, BS, DIN, GB, JIS |
Multi-Storey Steel Structure Warehouse/Prefabricated Steel Structure Building integrates real estate, construction and metallurgical industries into a new industrial system. This innovative building system is widely recognized as the future of construction technology.
Items | Specification |
---|---|
Main Steel Frame - Column | Q235, Q345 Welded H Section Steel |
Main Steel Frame - Beam | Q235, Q345 Welded H Section Steel |
Secondary Frame - Purlin | Q235 C and Z purlin |
Knee brace | Q235 Angle Steel |
Tie Rod | Q235 Circular Steel Pipe |
Brace | Q235 Round Bar |
Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe |
Maintenance system - Roof Panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet |
Maintenance system - Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
Accessories - Window | Aluminium Alloy Window / PVC Window / Sandwich Panel Window |
Accessories - Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
Rainspout | PVC |
Live load on Roof | 120kg/Sqm (Color steel panel surrounded) |
Wind Resistance Grade | 12 Grades |
Earthquake-resistance | 8 Grades |
Structure Usage | Up to 50 years |
Temperature | Suitable temperature: -50°C to +50°C |
Certification | CE, SGS, ISO9001:2008, ISO14001:2004 |
Finishing Options | Vast array of colors and textures available |
Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized |
Our steel structure fabrication facility spans 35,000㎡ with a workshop area of 20,000㎡. We operate three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various profiling steel sheet machines, equipped with advanced technology including plasma cutting machines.
Please provide the following information for an accurate quotation:
Question | Details Required |
---|---|
Location (where will be built?) | Country, area |
Size | Length × width × height (mm) |
Wind load (max. wind speed) | kn/m², km/h, or m/s |
Snow load (max. snow height) | kn/m² or mm |
Anti-earthquake | Level |
Brickwall needed or not | If yes, 1.2m high or 1.5m high |
Thermal insulation | If yes, specify material (EPS, fiberglass wool, rockwool, PU sandwich panels) |
Door quantity & size | Units, width × height (mm) |
Window quantity & size | Units, width × height (mm) |
Crane needed or not | If yes, specify units, max lifting weight (tons), and max lifting height (m) |
