Prefabricated Steel Workshop Building with Daylighting

Prefabricated Steel Workshop Building with Daylighting
Prefabricated Steel Workshop Building with Daylighting
Prefabricated Steel Workshop Building with Daylighting Prefabricated Steel Workshop Building with Daylighting Prefabricated Steel Workshop Building with Daylighting Prefabricated Steel Workshop Building with Daylighting Prefabricated Steel Workshop Building with Daylighting Prefabricated Steel Workshop Building with Daylighting Prefabricated Steel Workshop Building with Daylighting

Large Image :  Prefabricated Steel Workshop Building with Daylighting

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, ,ISO, BV
Model Number: Ruly0369
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Workshop Building with Daylighting

Description
Application: Prefabricated Steel Building Usage: Steel Structure Workshop
Type: Prefabricated Steel Frame Buildings Our Service: Design, Fabrication, Construction
Service Life: 50 Years Surface Treatment: Painting Or Hot-dip Galvanize
Wall And Roof: Steel Cladding Columns And Beam: H Section Column&Beam
Highlight:

SGS Metal Fabrication Workshop Steel Building

,

Prefabricated Workshop Steel Building

,

H Section Q345 Steel Structure Workshop

Metal Fabrication Workshop Steel Building Prefabricated With Daylighting
Product Specifications
Attribute Value
Application Prefabricated Steel Building
Usage Steel Structure Workshop
Type Prefabricated Steel Frame Buildings
Our service Design, Fabrication, Construction
Service life 50 Years
Surface treatment Painting or Hot-dip Galvanize
Wall and Roof Steel cladding
Columns and Beam H Section Column & Beam
Product Description

Our prefabricated steel building with daylighting offers superior structural advantages including high strength, light weight, excellent rigidity, and deformation resistance. Ideal for large-span, high-rise, and heavy-load constructions, this steel structure provides homogeneous and isotropic properties that perfectly meet engineering mechanics requirements.

Main Components & Technical Parameters
Main Steel Frame System
Main structure H section steel Q345, alkyd painting, two primary painting, two finish painting
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Bracing System
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Roof panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Wall panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Unpowered ventilator Diameter Φ600, stainless steel
Sky lighting band 1.2mm FRP, double layer
Key Advantages
  • High strength with light weight: Superior strength-to-weight ratio ideal for large-span and heavy-load structures
  • Exceptional durability: 50-year service life with proper maintenance
  • Efficient construction: Prefabricated components enable fast, precise installation
  • Environmental sustainability: Fully recyclable materials with minimal construction waste
  • Thermal performance: Specialized design eliminates thermal bridging issues
  • Seismic resistance: Excellent performance under dynamic loads and seismic activity
Packaging
Prefabricated Steel Workshop Building with Daylighting 0
