Prefabricated Steel Structure Office Building Q235B Q355B Material

Large Image : Prefabricated Steel Structure Office Building Q235B Q355B Material

Product Details:

Place of Origin:	China
Brand Name:	Ruly Steel
Certification:	SGS, BV, ISO
Model Number:	Ruly0356

Payment & Shipping Terms:

Minimum Order Quantity:	500 Square Meter
Price:	USD29-USD99 Per Square Meter
Packaging Details:	As request
Delivery Time:	30 Days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	20000 Square Meter Per Month

Contact Now

Prefabricated Steel Structure Office Building Q235B Q355B Material

Description

Features:	Steel Structure Office Building	Application:	Prefabricated Steel Structure Building
Type:	Industrial Steel Buildings	Raw Steel Material:	Q235B, Q355B
Surface Treatment:	Painting Or Hot-dip Galvanize	Service Life:	50 Years
Working Scope:	Design,Fabrication, Installation	Beam And Column:	H-section Steel, Latticed Steel, Box Steel
Highlight:	Prefabricated Multi Storey Office Building , Frame Structure Multi Storey Office Building

Prefabricated Steel Structure Building / Steel Structure Multi Storey Office Building

Product Specifications

Application	Prefabricated Steel Structure Building
Features	Steel Structure Office Building
Type	Industrial Steel Buildings
Raw steel material	Q235B, Q355B
Surface treatment	Painting or Hot-dip Galvanize
Service life	50 Years
Working scope	Design, Fabrication, Installation
Beam and Column	H-section steel, latticed steel, box steel

Product Overview

Our prefabricated steel structure buildings offer superior environmental benefits compared to conventional office buildings, with enhanced energy efficiency and reduced consumption. The factory-based prefabrication of main components enables dry construction that minimizes water and electricity usage while reducing environmental impact.

Project Specifications

Structure Type	Frame structure, flat roof
Dimensions	80m (Length) × 60m (Width) × 25m (Eave Height)
Roof Slope	10%
Steel Quantity	3500 Tons
Roof Material	75mm thick Rock wool sandwich panel
Wall Material	75mm thick Rock wool sandwich panel
Door Type	Sliding door
Window Type	Glass window
Height Difference	300mm between indoor and outdoor

Structural Components

Main Steel Frame System

Main structure: H section steel Q355 with alkyd painting (two primary coats, two finish coats)
Roof purlin: XZ160*60*20*2.5, galvanized
Wall purlin: XZ160*60*20*2.5, galvanized
Fasteners: Grade 10.9 intensive bolts, M20+2 turn buckle bolts, M24 anchor bolts

Bracing System

Cross brace: Φ20 round steel bar Q235, painted
Angle brace: L50*5 angle steel Q235, painted
Column bracing: Φ25 round steel bar Q235, painted
Tie bar: Φ127*3 steel pipe Q235, painted

Wall & Roof System

Roof panel: Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Wall panel: Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Ventilation: Φ600 stainless steel unpowered ventilator
Lighting: 1.2mm FRP sky lighting band, double layer

Factory Production

Why Choose Our Steel Structures

Cost-effective: Professional design reduces construction time and material usage
Eco-friendly: Specialized cladding materials provide excellent insulation; recyclable materials
Versatile: Spacious designs with flexible layouts and aesthetic profiles

Our Capabilities

We specialize in both light and heavy steel structure buildings, including warehouses, workshops, storage facilities, office buildings, factories, plants, and exhibition halls.

Request a Quote

Please provide the following information for an accurate quotation:

Location	_____country, area
Dimensions	_____mm × _____mm × _____mm (L×W×H)
Wind load	_____kn/m², _____km/h, _____m/s
Snow load	_____kn/m², _____mm
Earthquake resistance	_____level
Brick wall requirements	If yes, 1.2m high or 1.5m high
Thermal insulation	EPS, fiberglass wool, rockwool, PU sandwich panels or metal sheets
Door specifications	_____units, _____mm × _____mm (W×H)
Window specifications	_____units, _____mm × _____mm (W×H)
Crane requirements	If yes, _____units, max. _____tons lifting weight, _____m height
