Prefab Steel Structure Workshop with Crane for Heavy Industry

Prefab Steel Structure Workshop with Crane for Heavy Industry
Prefab Steel Structure Workshop with Crane for Heavy Industry
Prefab Steel Structure Workshop with Crane for Heavy Industry Prefab Steel Structure Workshop with Crane for Heavy Industry Prefab Steel Structure Workshop with Crane for Heavy Industry Prefab Steel Structure Workshop with Crane for Heavy Industry Prefab Steel Structure Workshop with Crane for Heavy Industry Prefab Steel Structure Workshop with Crane for Heavy Industry Prefab Steel Structure Workshop with Crane for Heavy Industry

Large Image :  Prefab Steel Structure Workshop with Crane for Heavy Industry

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0213
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter
Packaging Details: As request
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefab Steel Structure Workshop with Crane for Heavy Industry

Description
Application: Steel Structure Workshop With Crane Usage: Heavy Industrial Steel Structure Workshop
Type: Prefab Steel Structure Workshop Raw Steel Material: Q235B, Q355B, ASTM A36
Surface Treatment: Painting Or Hot-dip Galvanize Service Life: 50 Years
Wall And Roof: Glass Wool Working Scope: Design,Fabrication, Installation
Highlight:

prefab steel buildings

,

steel structure factory building

Heavy Industrial Steel Structure Workshop With Crane Prefab Designed 50 Years Service Life
Product Specifications
Attribute Value
Application Steel Structure Workshop With Crane
Usage Heavy Industrial Steel Structure Workshop
Type Prefab Steel Structure Workshop
Raw steel material Q235B, Q355B, ASTM A36
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Glass wool
Working scope Design, Fabrication, Installation
Product Description

Prefabricated heavy industrial steel structure workshops with crane systems feature portal steel frames typically used for buildings with spans of 9-36m, column spacing of 6m to 7.5m, and heights of 4.5m to 15m. Available in single or multiple span configurations, these structures support overhead cranes with lifting capacities from 3 to 35 tons.

Structural Components and Technical Parameters
Component Specification
Main Steel Frame (Column) Q235, Q345 Welded H Section Steel
Main Steel Frame (Beam) Q235, Q345 Welded H Section Steel
Secondary Frame (Purlin) Q235 C and Z purlin
Knee Brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical/Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Wind Resistance Grade 12
Earthquake Resistance Grade 8
Temperature Range -50°C to +50°C
Certifications CE, SGS, ISO9001:2008, ISO14001:2004
Service Scope
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Engineering consulting and shop drawing development
  • Project types include warehouses, workshops, storage sheds, garages, hangars, and commercial buildings
Prefab Steel Structure Workshop with Crane for Heavy Industry 0
Installation Methods
  • Detailed shop drawings provided prior to installation
  • On-site training and sample assembly available at our factory
Prefab Steel Structure Workshop with Crane for Heavy Industry 1
Packaging and Transportation

All components including panels, bolts, and accessories are packed in standard ocean transport containers (40'HQ). Our skilled workers use cranes and forklifts to ensure damage-free loading.

Prefab Steel Structure Workshop with Crane for Heavy Industry 2
Quotation Requirements

Please provide the following information for an accurate quote:

1 Project Location Country and area
2 Building Dimensions Length × Width × Height (mm)
3 Wind Load Maximum wind speed (kn/m², km/h, or m/s)
4 Snow Load Maximum snow height (kn/m² or mm)
5 Earthquake Resistance Required level
6 Brick Wall Requirements Height if needed (1.2m or 1.5m)
7 Thermal Insulation Material preference (EPS, fiberglass, rockwool, PU, or metal sheets)
8 Door Specifications Quantity and dimensions (width × height in mm)
9 Window Specifications Quantity and dimensions (width × height in mm)
10 Crane Requirements Quantity, maximum lifting weight (tons), and lifting height (m)
