Prefabricated Steel Workshop Building with Rock Wool Insulation

Prefabricated Steel Workshop Building with Rock Wool Insulation
Prefabricated Steel Workshop Building with Rock Wool Insulation
Prefabricated Steel Workshop Building with Rock Wool Insulation Prefabricated Steel Workshop Building with Rock Wool Insulation Prefabricated Steel Workshop Building with Rock Wool Insulation Prefabricated Steel Workshop Building with Rock Wool Insulation Prefabricated Steel Workshop Building with Rock Wool Insulation Prefabricated Steel Workshop Building with Rock Wool Insulation Prefabricated Steel Workshop Building with Rock Wool Insulation

Large Image :  Prefabricated Steel Workshop Building with Rock Wool Insulation

Product Details:
Place of Origin: China
Brand Name: Ruly Steel
Certification: SGS, BV, ISO
Model Number: Ruly0210
Payment & Shipping Terms:
Minimum Order Quantity: 300 Square Meter
Price: USD29-USD99 Per Square Meter
Packaging Details: Steel frame pallets and loaded into 40’HQ
Delivery Time: 30 Days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 20000 Square Meter Per Month
Contact Now

Prefabricated Steel Workshop Building with Rock Wool Insulation

Description
Application: Prefabricated Workshop Buildings , Industrial Steel Framed Buildings Type: Steel Structure Workshop
Raw Steel Material: Q235B, Q355B, ASTM A36 Shot Blasting Level: Sa 2.5
Service Life: 50 Years Wall And Roof: Rock Wool
Surface Treatment: Painting Working Scope: Design,Fabrication, Installation
Columns & Beams: H-section Steel Standard: AISC, ASTM, BS, DIN, GB, JIS
Highlight:

steel structure factory building

,

metal workshop building

Prefabricated Steel Structure Workshop Industrial Steel Framed Buildings
Product Specifications
Attribute Value
Application Prefabricated Workshop Buildings, Industrial Steel Framed Buildings
Type Steel Structure Workshop
Raw steel material Q235B, Q355B, ASTM A36
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Rock wool
Surface treatment Painting
Working scope Design, Fabrication, Installation
Columns & Beams H-section steel
Standard AISC, ASTM, BS, DIN, GB, JIS
Product Description
Our prefabricated steel structure workshops are engineered for industrial applications, combining high-strength steel framing with durable materials for long-lasting performance. The welded H-section steel columns and beams form a robust main frame structure, connected by high-strength bolts for superior stability.
Structural Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel plate thickness: 8-30mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Roof System Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Wall System Purlin: C160*60*2.5, Steel Q235, painted
Our Manufacturing Facility
Our 35,000㎡ steel structure fabrication factory includes 20,000㎡ of workshop space equipped with advanced production lines for H steel, BOX sections, C/Z purlins, and profiling steel sheets. Our facility features plasma cutting machines and other state-of-the-art equipment for precision fabrication.
Prefabricated Steel Workshop Building with Rock Wool Insulation 0
Service Scope
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Prefabricated Steel Workshop Building with Rock Wool Insulation 1
Packing and Transportation
All structural components, panels, bolts, and accessories are carefully packed in standard ocean transportation packages (40'HQ containers). Our skilled workers use cranes and forklifts to ensure safe loading and prevent damage during transport.
Prefabricated Steel Workshop Building with Rock Wool Insulation 2
